System And Components
503-7634 MOUNTING GP-CEMS/N DN81-UP
Group No: 503-7634
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5770235 | 1 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5888345 | 2 TUBE AS | 1 | |
| 5888346 | 3 TUBE AS | 1 | |
| 3430596 | 4 CLAMP-BAND | 2 | |
| 7X2553 | 5 BOLT (M16X2X40-MM) | 8 | |
| 7X7729 | 6 WASHER (11X25X3-MM THK) | 6 | |
| 8T4195 | 7 BOLT (M10X1.5X30-MM) | 6 | |
| 9X8257 | 8 WASHER (17.5X30X3.5-MM THK) | 8 | |
| 7W2033 | 9 CLIP (TAB) | 2 | |
| 7W2034 | 10 CLIP (SLOT) | 2 |
