System And Components
344-7508 LINES GP-ENGINE OILS/N MJ91-UP
Group No: 344-7508
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7I4949 | 1 TUBE | 3 | |
| 1239052 | 2 COVER | 1 | |
| 2147568 | 3 SEAL-O-RING | 2 | |
| 2385080 | 4 SEAL-O-RING | 2 | |
| 2395571 | 5 SEAL-INTEGRAL | 1 | |
| 3527760 | 6 TUBE AS | 1 | |
| 3539429 | 7 TUBE AS | 1 | |
| 3539430 | 8 TUBE AS | 1 | |
| 3615963 | 9 TUBE AS | 1 | |
| 0308188 | 10 CONNECTOR | 2 | |
| 0S1591 | 11 BOLT (3/8-16X1.5-IN) | 3 | |
| 1D4540 | 12 BOLT (5/16-18X2.75-IN) | 3 | |
| 1W7474 | 13 STUD (3/8-16X2.25-IN) | 1 | |
| 2R6806 | 14 CONNECTOR | 2 | |
| 3256994 | 15 CLIP (SLOT) | 1 | |
| 3256995 | 16 CLIP (TAB) | 1 | |
| 3532471 | 17 CLIP | 4 | |
| 3537956 | 18 GROMMET | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 6B2882 | 20 SPACER (0.406X0.75X0.312-IN THK) | 1 | |
| 7K4129 | 21 UNION-FLARED | 1 | |
| 9M1974 | 22 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 2 |
