System And Components
386-3801 LINES GP-TURBOCHARGER WATERS/N TXE1-UP
Group No: 386-3801
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3664678 | 1 CONNECTOR AS | 2 | |
| 8C6872 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3863799 | 2 HOSE AS-WATER | 1 | |
| 3920803 | 3 CONNECTOR AS | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 8T1888 | 4 CLIP (TAB) | 1 | |
| 1444613 | 5 ANGLE AS | 1 | |
| 3884731 | 6 HOSE & TUBE AS | 1 | |
| 1808424 | 7 SEAL-O-RING | 1 | |
| 4P7233 | 8 GROMMET | 1 | |
| 6V4248 | 9 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5839 | 10 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V6317 | 11 BOLT (M10X1.5X20-MM) | 1 | |
| 8T1887 | 12 CLIP (SLOT) | 1 |
