System And Components
386-0017 AFTERCOOLER GP-AIRS/N 9SD1-UP
Group No: 386-0017
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1869526 | 1 CORE | 1 | |
| 1869089 | 2 GASKET | 2 | |
| 1869559 | 3 BAR-ROUND | 4 | |
| 2100014 | 4 PLATE-SPACER | 4 | |
| 3860023 | 5 TANK AS (LH) | 1 | |
| 3860024 | 6 TANK AS (RH) | 1 | |
| 3860025 | 7 SUPPORT AS-UPPER | 1 | |
| 4K0367 | NUT-FULL (5/8-11-THD) | 2 | |
| 5S0003 | NUT (5/16-18-THD) | 6 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 4 | |
| 3860026 | 8 SUPPORT AS-LOWER | 1 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 10 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 4 | |
| 1B7182 | 10 BOLT (5/16-18X1.25-IN) | 38 | |
| 0S1618 | 11 BOLT (5/16-18X1-IN) | 14 | |
| 0314155 | 12 LOCKNUT (5/16-18-THD) | 60 | |
| 4394135 | 13 PLATE | 4 | |
| 4395581 | 14 PLUG | 2 | |
| 1A9579 | 15 BOLT (5/16-18X1.5-IN) | 4 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 64 |
