System And Components
161-1244 ENGINE ARS/N AGJ1-115; AGL1-214
Group No: 161-1244
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1596000 | 1 ENGINE AR | 1 | |
| 1607396 | 2 SOLENOID GP-THROTTLE | 1 | |
| 1689056 | 3 HOSE AS | 1 | |
| 2P9697 | 4 PLUG | 1 | |
| 9X2488 | 5 CLAMP-HOSE | 1 | |
| 7J1908 | 6 SEAL | 3 | |
| 1118206 | 7 BRACKET | 1 | |
| 1089451 | 8 MANIFOLD-ENGINE SENSOR | 1 | |
| 1034977 | 9 SWITCH AS-PRESSURE (ENGINE OIL) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1620782 | 10 SWITCH AS-PRESSURE (ENGINE OIL) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 3 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552276 | WEDGE-PLUG LOCK (3-PIN) | 1 | |
| 1058056 | 11 SENDER AS-PRESSURE (ENGINE OIL) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 6T2665 | 12 SWITCH AS-TEMPERATURE (COOLANT) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3E6449 | 13 SWITCH AS-TEMPERATURE (COOLANT) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 7W9943 | 14 SENDER-TEMPERATURE (COOLANT) | 1 | |
| 4B4274 | WASHER (5.5X13X1.2-MM THK) | 1 | |
| 6V8378 | NUT (10-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 2 | |
| 8T2501 | 16 BOLT (3/8-16X2-IN) | 2 | |
| 6V8801 | 17 NUT (3/8-16-THD) | 1 | |
| 6L9952 | 18 ADAPTER | 1 | |
| 7C4355 | 19 CLIP | 1 | |
| 8C6865 | 20 CONNECTOR | 1 | |
| 4J5477 | 21 SEAL-O-RING | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 3D2824 | 24 SEAL-O-RING | 1 | |
| 6V8627 | 25 ELBOW | 1 | |
| 3J1907 | 26 SEAL-O-RING | 1 | |
| 6V2455 | 27 SENSOR GP-SPEED (ENGINE) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 9X1386 | SLEEVE | ||
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 1121795 | 28 HOSE AS | 1 | |
| 1597919 | 29 STARTING MOTOR GP-ELECTRIC | 1 | |
| 9Y8187 | 30 ALTERNATOR GP-CHARGING | 1 | |
| 1607395 | 31 MODULE GP-TIMER | 1 | |
| 4L6454 | 32 BOLT (3/8-16X1-IN) | 1 | |
| 9L1127 | 33 V-BELT SET (INCLUDES 2-BELTS) | 1 | |
| 1032529 | 34 HOSE (175CM) | ||
| 0960061 | 35 STRAP-CABLE | 1 | |
| 1039408 | 36 VALVE GP-FLUID SAMPLING (MANUAL) | 1 | |
| 1109674 | 37 GAUGE GP-OIL LEVEL (DIPSTICK) | 1 | |
| 1030803 | 38 FILLER GP-ENGINE OIL | 1 | |
| 1597574 | 39 PUMP GP-FUEL PRM & PRIM FILTER | 1 | |
| 4P2843 | 40 PULLEY | 1 | |
| 6V5230 | 41 BOLT (M10X1.5X60-MM) | 8 | |
| 1192919 | 42 TUBE AS | 1 | |
| 7C7911 | 43 ELBOW | 1 | |
| 6V8724 | 44 ELBOW | 1 | |
| 6V5192 | 45 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 1 | |
| 5A3604 | 46 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 1 | |
| 6V8187 | 47 NUT (1/4-28-THD) | 3 | |
| 9L2685 | 48 BALL JOINT AS | 1 | |
| 1197018 | 49 BALL JOINT | 1 | |
| 1485603 | 50 BRACKET | 1 | |
| 5C2890 | 51 NUT (M6X1-THD) | 4 | |
| 5P4115 | 52 WASHER-HARD (7.2X19X2-MM THK) | 7 | |
| 8T4138 | 53 BOLT (M6X1X20-MM) | 6 | |
| 6V7697 | 54 SCREW-MACHINE (8-32X1.25-IN) | 2 | |
| 4B4863 | 55 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 6D5801 | 56 LOCKNUT (8-32-THD) | 2 |
