227-5102 ENGINE ARS/N B2G1-UP; A3P1-UP

Group No: 227-5102

Part Number	Part Name	Qty
1595999	1 ENGINE AR	1
1083858	2 STARTING MOTOR GP-ELECTRIC	1
1833633	3 HOSE AS	1
1654935	4 PLUG AS	1
6V9510	PLUG (1-14-THD)	1
7J9108	SEAL-O-RING	1
9X2488	5 CLAMP-HOSE	1
3K0360	6 SEAL-O-RING	2
1488331	7 CONNECTOR AS	1
3J1907	SEAL-O-RING	1
3Y2888	CONNECTOR	1
6V1240	8 TEE-PIPE	1
1620782	9 SWITCH AS-PRESSURE (ENGINE OIL)	1
1028803	KIT-RECEPTACLE (3-PIN)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	3
1039408	10 VALVE GP-FLUID SAMPLING (COOLANT)	1
2953145	11 SENDER AS-PRESSURE (ENGINE OIL)	1
4B2049	NUT (10-32-THD)	1
8F1434	LOCKWASHER	1
2033219	12 SWITCH AS-TEMPERATURE (COOLANT)	1
6V8376	SCREW-MACHINE (8-32X0.25-IN)	2
9B7233	LOCKWASHER	2
3E6449	13 SWITCH AS-TEMPERATURE (COOLANT)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	2
1028802	KIT-RECEPTACLE (2-PIN)	1
7W9943	14 SENDER-TEMPERATURE (ENGINE COOLANT)	1
9Y8187	15 ALTERNATOR GP-CHARGING	1
9L1226	16 V-BELT SET (INCLUDES 2-BELTS)(ALTERNATOR)	1
1895746	17 SENSOR GP-SPEED (ENGINE)	1
1943886	18 ADAPTER AS	1
3D2824	SEAL-O-RING	1
6L9952	ADAPTER	1
7C4355	19 CLIP	1
1607396	20 SOLENOID GP-THROTTLE	1
1834788	21 ROD	1
1197018	22 BALL JOINT	1
9L2685	23 BALL JOINT AS	1
1607395	24 MODULE GP-TIMER	1
2275101	25 BRACKET AS	1
4V7717	BOSS (3/8-16-THD)	1
4B4863	26 WASHER (4.7X11X1.2-MM THK)	2
6V7697	27 SCREW-MACHINE (8-32X1.25-IN)	2
6D5801	28 LOCKNUT (8-32-THD)	2
5P4115	29 WASHER-HARD (7.2X19X2-MM THK)	7
5C9553	30 BOLT (M6X1X16-MM)	6
5C2890	31 NUT (M6X1-THD)	4
1160118	32 CLIP	2
6V8187	33 NUT (1/4-28-THD)	3
1H3338	34 LOCKWASHER	1
8T4896	35 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
8T9371	36 BOLT (3/8-16X0.5-IN)	1
