System And Components
264-9050 DRIVE GP-BRUSH CUTTER -78-INS/N RDN1-UP
Group No: 264-9050
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2K7471 | 1 LOCKNUT (1-14-THD) | 2 | |
| 3B4631 | 2 PIN-COTTER | 1 | |
| 3E9862 | 3 LOCKNUT (3/4-10-THD) | 4 | |
| 4B9807 | 4 SETSCREW | 2 | |
| 7X0325 | 5 BOLT (1/2-13X2.5-IN) | 4 | |
| 8T4994 | 6 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 9X0941 | 8 LOCKNUT (1/2-13-THD) | 5 | |
| 2649033 | 9 MANIFOLD GP-CONTROL | 1 | |
| 2649051 | 10 BLADE (INCLUDES 2-BLADES) | 1 | |
| 2649054 | 11 COUPLING | 1 | |
| 2649560 | 12 GEARBOX GP | 1 | |
| 2659381 | 13 MOTOR GP-GEROTOR | 1 | |
| 2806820 | 14 PIN | 2 | |
| 2916547 | 15 CARRIER AS | 1 | |
| 1781695 | 16 BOLT-SOCKET HEAD (3/8-16X3.5-IN) | 8 | |
| 2731683 | 17 NUT-HEX SLOTTED (1-14-THD) | 1 | |
| 2735754 | 18 BOLT (1/2-13X3.5-IN) | 1 | |
| 3B4508 | 19 LOCKWASHER | 5 | |
| 8T5361 | 20 WASHER-HARD (28X49X5-MM THK) | 2 | |
| 4J5267 | 21 SEAL-O-RING | 2 |
