Assembly
100%

242-3480 LINES GP-AUXILIARY SEA WATERFOR USE WITH COMPACT MARINE ENGINES

Group No: 242-3480
Part NumberPart NameQty
8T67031 CLAMP-HOSE8
10116402 SLEEVE2
12304883 TUBE AS1
24232814 HOSE1
24338175 TUBE AS1
25345076 BRACKET1
10518667 CLIP1
25898818 CLIP-2 PIECE1
25898829 CLIP-2 PIECE1
2Y582910 NUT (M10X1.5-THD)2
5P053711 WASHER-HARD (7.2X14.5X2-MM THK)4
6L165112 SEAL-O-RING2
6V583913 WASHER (11X21X2.5-MM THK)4
6V584214 BOLT (M10X1.5X40-MM)2
6V231615 BOLT (M8X1.25X12-MM)1
6V883716 BOLT (M6X1X16-MM)4
7X087017 BOLT (M8X1.25X140-MM)2
9M197418 WASHER-HARD (8.8X16X2-MM THK)5
038415019 HOSE1
