System And Components
445-6229 LINES GP-FUEL INJECTIONAN ATTACHMENT
Group No: 445-6229
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 8 | |
| 1081434 | GROMMET | 1 | |
| 7C7683 | 2 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 2609219 | 3 CONNECTOR AS | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2815977 | 4 CONNECTOR AS | 3 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3196220 | 5 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3535096 | 6 CONNECTOR AS | 1 | |
| 8T9386 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3717187 | 7 PLUG AS | 4 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3603683 | PLUG | 1 | |
| 3893708 | 8 PLUG AS | 5 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3893709 | 9 PLUG AS | 11 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3985601 | 10 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 4264024 | 11 ADAPTER AS | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4346464 | 12 VALVE GP-CHECK | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4373327 | VALVE-CHECK | 1 | |
| 4391835 | 13 ADAPTER AS | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4391834 | ADAPTER-CROSS | 1 | |
| 4391889 | 14 ELBOW AS | 1 | |
| 1292327 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 4435159 | 15 TUBE AS | 1 | |
| 4435161 | 16 TUBE AS | 1 | |
| 4435165 | 17 TUBE AS | 1 | |
| 4435168 | 18 HOSE AS | 1 | |
| 4435192 | 19 HOSE AS | 1 | |
| 4451800 | 20 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4456210 | 21 HOSE AS | 1 | |
| 4456223 | 22 BRACKET | 1 | |
| 4456245 | 23 HOSE AS | 1 | |
| 4459606 | 24 HOSE AS | 1 | |
| 4459607 | 25 HOSE AS | 1 | |
| 4524687 | 26 TUBE AS | 1 | |
| 4524688 | 27 TUBE AS | 1 | |
| 2287091 | 28 SEAL-O-RING | 4 | |
| 2287093 | 29 SEAL-O-RING | 4 | |
| 2681605 | 30 ELBOW AS | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2815933 | 31 ELBOW AS | 2 | |
| 6V9853 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815975 | 32 ELBOW AS | 2 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3218648 | 33 CONNECTOR AS | 2 | |
| 2T2991 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3295526 | 34 UNION AS | 1 | |
| 6V8996 | UNION | 1 | |
| 2287091 | SEAL-O-RING | 2 | |
| 3537955 | 35 GROMMET | 1 | |
| 3E4352 | 36 WASHER-HARD (8.8X20.5X2.5-MM THK) | 3 | |
| 3E4353 | 37 WASHER-HARD (11X25X3-MM THK) | 3 | |
| 6V1820 | 38 BOLT (M10X1.5X30-MM) | 1 | |
| 6V3940 | 39 BOLT (M8X1.25X25-MM) | 3 | |
| 6V8732 | 40 UNION | 1 | |
| 6V8996 | 41 UNION | 1 | |
| 6V8998 | 42 UNION | 2 | |
| 6V9170 | 43 NUT-BULKHEAD (1-14-THD) | 1 | |
| 6V9172 | 44 NUT (1-7/16-12-THD) | 2 | |
| 8T0100 | 45 BOLT (M8X1.25X60-MM) | 1 | |
| 8T0355 | 46 BOLT (M10X1.5X110-MM) | 2 | |
| 8T0358 | 47 BOLT (M16X2X90-MM) | 4 | |
| 8T1887 | 48 CLIP (SLOT) | 1 | |
| 8T1888 | 49 CLIP (TAB) | 1 | |
| 9M1974 | 50 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X8268 | 51 WASHER (17.5X30X3.5-MM THK) | 4 |
