199-3154 LINES GP-FUELS/N CKH146-173

Group No: 199-3154
Part NumberPart NameQty
1P04361 GASKET (FUEL PRIMING PUMP)1
3G40052 LINK2
4D77353 CLIP1
5K86524 BRACKET1
11390015 HOSE AS1
13755416 PUMP GP-FUEL PRIMING1
15657837 VALVE GP-CHECK (FUEL)1
18354258 HOSE AS1
19794419 HOSE AS3
204013010 BRACKET1
223634511 MANIFOLD-FUEL1
230246212 SUPPORT AS1
7W9094SPACER (11X20X9-MM THK)1
8T5912NUT-WELD (3/8-16-THD)2
230246313 TUBE AS1
231195414 TUBE AS1
231277015 TUBE AS1
005436216 ELBOW1
030793617 CONNECTOR1
030794718 ADAPTER-ELBOW2
118472819 ELBOW1
030819420 CONNECTOR1
033604221 SEAL-O-RING4
067255122 CLIP1
0S158823 BOLT (3/8-16X1.25-IN)2
0S159024 BOLT (3/8-16X2-IN)2
0S159225 BOLT (5/8-11X1.25-IN)1
0S159426 BOLT (3/8-16X1-IN)4
0T006527 BOLT (3/8-16X3.5-IN)2
101312128 SPACER (10.5X25X25-MM THK)4
186035729 CLIP1
1A202930 BOLT (3/8-16X1.125-IN)1
1B718231 BOLT (5/16-18X1.25-IN)2
2R680632 CONNECTOR2
3J190733 SEAL-O-RING1
4D779434 CLIP6
5K533835 CLIP (LOOP)1
5M289436 WASHER-HARD (10.2X18.5X2.5-MM THK)14
5P053737 WASHER-HARD (7.2X14.5X2-MM THK)1
5P824738 WASHER-HARD (17X32X3.5-MM THK)1
6K919439 ELBOW1
6V458940 SEAL-O-RING2
6V504841 SEAL-O-RING5
6V504942 SEAL-O-RING6
6V839743 SEAL-O-RING3
6V864144 CONNECTOR1
6V872445 ELBOW2
7B274246 BOLT (1/4-20X1.25-IN)1
8L278647 SEAL-O-RING2
9M197448 WASHER-HARD (8.8X16X2-MM THK)2
9S418249 PLUG (7/16-20-THD)1
9S419150 PLUG (9/16-18-THD)2
9S800251 PLUG (7/16-20-THD)(MARKED Y)4
9S800452 PLUG (9/16-18-THD)1
9S875253 NUT-FULL (3/8-16-THD)3
