System And Components
304-9983 AIR COMPRESSOR GPS/N JAM247-482
Group No: 304-9983
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X2097 | 1 STUD (M8X1.25-THD) | 3 | |
| 1994317 | 2 BOLT (M10X1.5X115-MM) | 6 | |
| 2675212 | 3 RING-RETAINING | 2 | |
| 2871690 | 4 GASKET | 1 | |
| 2881347 | 5 PLUG | 2 | |
| 3076192 | 6 GASKET | 1 | |
| 3076200 | 7 GASKET | 1 | |
| 2718090 | 8 BOLT-FLANGE HEAD (M6X1X65-MM) | 3 | |
| 3J1907 | 9 SEAL-O-RING | 1 | |
| 3K0360 | 10 SEAL-O-RING | 1 | |
| 5E8769 | 11 SEAL-O-RING | 1 | |
| 6D7889 | 12 SEAL-O-RING | 2 | |
| 6V3940 | 13 BOLT (M8X1.25X25-MM) | 1 | |
| 6V5839 | 14 WASHER (11X21X2.5-MM THK) | 6 | |
| 9S4185 | 15 PLUG (3/4-16-THD) | 1 | |
| 9S4191 | 16 PLUG (9/16-18-THD) | 1 | |
| 3076205 | KIT-UNLOADER (AIR COMPRESSOR) | 1 | |
| 3076209 | KIT-CYLINDER HEAD (AIR COMPRESSOR) | 1 |
