System And Components
246-8835 COOLER GP-ENGINE OILPROVIDES 24 VOLT OIL COOLER GP FOR LOW CAB FORWARD SYSTEM THAT CONTAINS COOLER CORE, BONNETS, CONNECTION ELBOWS AND FASTENERS
Group No: 246-8835
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1245043 | 1 COUPLING | 1 | |
| 1616963 | 2 CLAMP | 2 | |
| 2242675 | 3 SEAL | 1 | |
| 1316645 | 4 HOSE | 1 | |
| 2246360 | 5 SEAL | 1 | |
| 2263571 | 6 SEAL-O-RING | 1 | |
| 4402907 | 7 ELBOW | 1 | |
| 6V1355 | 8 ELBOW | 1 | |
| 3493311 | 9 BONNET (OIL COOLER) | 1 | |
| 2368745 | 10 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 2407340 | 11 VALVE & MTG GP-DIVERTER (COOLANT) | 1 | |
| 2411662 | 12 TUBE AS | 1 | |
| 2N5243 | 13 SEAL-O-RING | 2 | |
| 6V2317 | 14 BOLT (M8X1.25X30-MM) | 5 | |
| 6V3251 | 15 SEAL-O-RING | 1 | |
| 6V3940 | 16 BOLT (M8X1.25X25-MM) | 2 | |
| 6V5063 | 17 SEAL-O-RING | 1 | |
| 6V5064 | 18 SEAL-O-RING | 3 | |
| 6V5219 | 20 BOLT (M8X1.25X40-MM) | 10 | |
| 6V5221 | 21 BOLT (M8X1.25X80-MM) | 1 | |
| 6V9027 | 22 SEAL-O-RING | 2 | |
| 3359214 | 23 CLAMP-BAND | 2 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 18 | |
| 9S8002 | 25 PLUG (7/16-20-THD) | 1 | |
| 9S8006 | 26 PLUG (7/8-14-THD) | 1 | |
| 9S8008 | 27 PLUG (1-1/16-12-THD) | 1 | |
| 9S9334 | 28 PLUG (1-5/16-12-THD) | 3 | |
| 2423360 | 29 HOSE (9-CM) | ||
| 3411429 | 30 SEAL | 1 |
