System And Components
297-6993 PUMP GP-HYDRAULICS/N LGK1-UP
Group No: 297-6993
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2052909 | 1 SHAFT-PUMP | 1 | |
| 8C3110 | 2 RING-RETAINING | 1 | |
| 1660344 | 3 SEAL-SHAFT | 2 | |
| 9S8006 | 4 PLUG (7/8-14-THD) | 1 | |
| 2M9780 | 5 SEAL-O-RING | 1 | |
| 1886303 | 6 SPRING | 1 | |
| 2747452 | 7 LINK-CONTROL | 1 | |
| 1886299 | 8 PISTON | 1 | |
| 3107792 | 9 PLUG | 1 | |
| 8T7525 | 10 SEAL-O-RING | 1 | |
| 9X8979 | 11 DOWEL | 1 | |
| 1683504 | 12 SEAL | 1 | |
| 1204394 | 13 PLUG-BREAK OFF | 1 | |
| 0950670 | 14 BOLT (M12X1.75X45-MM) | 4 | |
| 8T8442 | 15 BOLT-SOCKET HEAD (M6X1X30-MM) | 1 | |
| 3J7354 | 16 SEAL-O-RING | 1 | |
| 1279485 | 17 SEAL-O-RING | 1 | |
| 2426903 | 18 SHIM (3-MM THK) | 1 | |
| 2585193 | 19 ROTATING GP-PUMP | 1 | |
| 1971762 | 20 SWASHPLATE | 1 | |
| 1886320 | 21 BEARING | 2 | |
| 1850263 | 22 BEARING | 1 | |
| 9S8002 | 23 PLUG (7/16-20-THD) | 1 | |
| 2855240 | 24 VALVE GP-PUMP CONTROL (PRESSURE, FLOW COMPENSATOR) | 1 | |
| 2807870 | 25 GASKET | 1 | |
| 2038609 | 26 CUP-BEARING | 1 | |
| 1053035 | 27 CONE-BEARING | 1 |
