System And Components
488-3712 ENCLOSURE GP-GENERATORPART OF 498-3210 ENCLOSURE GP, 507-5038 ENCLOSURE GP-ENGINE
Group No: 488-3712
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y7066 | 1 WASHER (12.7X18X3-MM THK) | 4 | |
| 4608990 | 2 STRIKER | 1 | |
| 4755147 | 3 LATCH AS | 2 | |
| 4883707 | 4 DOOR GP-ACCESS | 2 | |
| 4883709 | 5 PANEL-ROOF | 1 | |
| 4883711 | 6 DUCT AS | 2 | |
| 4890955 | 7 PANEL AS | 1 | |
| 4890956 | 8 PANEL AS-END | 1 | |
| 4891809 | 9 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 1H3338 | 10 LOCKWASHER | 4 | |
| 0996418 | 11 NUT (M6X1-THD) | 4 | |
| 1004830 | 12 BOLT (M10X1.5X20-MM) | 8 | |
| 3401530 | 14 BOLT-FLANGE HEAD (M6X1X18-MM) | 10 | |
| 3445673 | 15 NUT (M6X1-THD) | 8 | |
| 5C9553 | 16 BOLT (M6X1X16-MM) | 4 | |
| 8T9388 | 17 BOLT (M10X1.5X25-MM) | 4 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 8 | |
| 3987367 | 19 SEAL (9-DM EACH) | ||
| 3987367 | 19A SEAL (11-DM EACH) | ||
| 1428194 | 20 RIVET | 8 | |
| 5080316 | 21 BRACKET | 1 | |
| 3445674 | 22 NUT (M8X1.25-THD) | 1 | |
| 8T4224 | 23 WASHER-HARD (8.8X16X2-MM THK) | 2 |
