System And Components
425-3332 LINES GP-DIESEL EXHAUST FLUIDS/N JTR1-UP
Group No: 425-3332
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 7 | |
| 2143509 | 2 BRACKET AS | 1 | |
| 2638727 | 3 BRACKET AS | 2 | |
| 2662404 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1246998 | PLATE | 1 | |
| 2945076 | 5 PLATE AS | 2 | |
| 3652240 | 6 LINE AS-DIESEL EXHAUST FLUID | 1 | |
| 4246231 | BUTTON | 2 | |
| 4458760 | 7 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4495407 | 8 ISOLATOR | 4 | |
| 5019519 | 9 HOSE AS | 1 | |
| 4246232 | BUTTON | 2 | |
| 5180074 | 10 HOSE AS | 1 | |
| 4246232 | BUTTON | 2 | |
| 4779610 | 11 PLATE AS | 1 | |
| 4806312 | 12 BRACKET AS | 1 | |
| 0993649 | 13 BOLT (M8X1.25X40-MM) | 4 | |
| 1769237 | 14 BOLT-SPECIAL (M10X1.5-THD) | 1 | |
| 1984777 | 15 WASHER-HARD (11X25X10-MM THK) | 7 | |
| 1S0994 | 16 CLIP (LOOP) | 13 | |
| 3445674 | 17 NUT (M8X1.25-THD) | 4 | |
| 3445675 | 18 NUT (M10X1.5-THD) | 3 | |
| 3523964 | 19 CLIP (LADDER) | 1 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6D4247 | 21 CLIP | 2 | |
| 7N0900 | 22 SPACER (0.423X0.675X2.38-IN) | 1 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 4 | |
| 8S0948 | 24 CLIP | 8 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4136 | 26 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4178 | 27 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4186 | 28 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4191 | 29 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 30 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 31 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6466 | 33 BOLT (M10X1.5X60-MM) | 4 |
