System And Components
481-6230 RADIATOR GPS/N NR61-UP
Group No: 481-6230
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N2807 | 1 HOSE | 1 | |
| 2647111 | 2 HOSE | 3 | |
| 2647112 | 3 HOSE | 1 | |
| 3065412 | 4 HOSE | 2 | |
| 3842243 | 5 BRACKET | 1 | |
| 4824108 | 6 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5154951 | ADAPTER | 1 | |
| 4363033 | 7 RADIATOR AS | 1 | |
| 4751478 | 8 FAN AS | 1 | |
| 4751479 | FAN (9-BLADES) | 1 | |
| 5P2228 | BOLT (1/2-13X1-IN) | 6 | |
| 8T4223 | WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 4751497 | 9 PIPE | 1 | |
| 4751498 | 10 PIPE AS | 1 | |
| 4751499 | 11 PIPE AS | 1 | |
| 3B6488 | COUPLING-PIPE | ||
| 7F9504 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 4751500 | 12 PIPE AS | 1 | |
| 3B6488 | COUPLING-PIPE | 1 | |
| 7F9504 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 4751503 | 13 CLAMP | 1 | |
| 4816242 | 14 PLATE | 2 | |
| 4845203 | 15 BRACKET | 1 | |
| 4845204 | 16 BRACKET | 1 | |
| 4845220 | 17 GUARD GP-RADIATOR | 1 | |
| 1440367 | 18 CLAMP-HOSE | 2 | |
| 1P4278 | 19 CLAMP-HOSE | 1 | |
| 3429913 | 20 BOLT-FLANGE HEAD (M10X1.5X20-MM) | 5 | |
| 3445675 | 21 NUT (M10X1.5-THD) | 4 | |
| 8C3089 | 23 SEAL-O-RING | 1 | |
| 7X7729 | 24 WASHER (11X25X3-MM THK) | 8 | |
| 8T6466 | 25 BOLT (M10X1.5X60-MM) | 4 | |
| 8T4984 | 26 CLAMP-HOSE | 6 | |
| 8T4985 | 27 CLAMP-HOSE | 2 | |
| 9X2201 | 28 CLAMP-HOSE | 4 | |
| 7K1181 | 29 STRAP-CABLE | 1 | |
| 4231980 | 30 HOSE (59-IN) |
