System And Components
432-4330 LINES GP-FUELS/N H3G1-UP
Group No: 432-4330
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 2 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 3196217 | 3 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3599291 | 4 HOSE AS | 1 | |
| 3985596 | 5 PLUG AS | 2 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 4308486 | 6 TUBE AS-FUEL | 1 | |
| 4308487 | 7 HOSE AS | 2 | |
| 1645567 | 8 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P4278 | 9 CLAMP-HOSE | 1 | |
| 2379159 | 10 SPACER (11X19X12-MM THK) | 1 | |
| 2501424 | 11 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2609221 | 12 ELBOW AS | 1 | |
| 9X2085 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2Y5829 | 13 NUT (M10X1.5-THD) | 1 | |
| 3196225 | 14 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196226 | 15 ELBOW AS | 2 | |
| 8T6876 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3196240 | 16 CONNECTOR AS | 2 | |
| 6V9873 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3537953 | 17 GROMMET | 1 | |
| 3537957 | 18 GROMMET | 1 | |
| 6V0852 | 19 CAP-DUST | 1 | |
| 6V5839 | 20 WASHER (11X21X2.5-MM THK) | 1 | |
| 5P5991 | 21 HOSE (0.3-M) | ||
| 8T1887 | 22 CLIP (SLOT) | 1 | |
| 8T1888 | 23 CLIP (TAB) | 1 | |
| 8T1889 | 24 CLIP (SLOT) | 1 | |
| 8T1890 | 25 CLIP (TAB) | 1 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 27 BOLT (M10X1.5X20-MM) | 1 | |
| 8C5064 | 28 CONDUIT-FLEXIBLE (17.75-MM ID, SPLIT)(21-CM) |
