System And Components
458-8815 FILTER GP-ENGINE OILALSO AN ATTACHMENT
Group No: 458-8815
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C1493 | 1 VALVE AS-BYPASS (ENGINE OIL COOLER) | 2 | |
| 2097290 | 2 GASKET | 1 | |
| 2423864 | 3 SPRING | 2 | |
| 3095131 | 4 PLUG AS | 2 | |
| 9S8006 | 4A PLUG (7/8-14-THD) | 1 | |
| 2385081 | 4B SEAL-O-RING | 1 | |
| 3445148 | 5 BASE AS-OIL FILTER | 1 | |
| 2P4304 | 5A STUD-HOLLOW | 1 | |
| 3474428 | 5B PLUG AS | 4 | |
| 2305040 | PLUG | 1 | |
| 2385085 | SEAL-O-RING | 1 | |
| 3779594 | 6 CONNECTOR AS | 1 | |
| 8K4739 | 6A ADAPTER | 1 | |
| 2385081 | 6B SEAL-O-RING | 1 | |
| 3985596 | 7 PLUG AS | 2 | |
| 2385080 | 7A SEAL-O-RING | 1 | |
| 3603680 | 7B PLUG (3/4-16-THD) | 1 | |
| 1R1808 | 8 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 1 | |
| 3218649 | 9 VALVE AS-FLUID SAMPLING | 1 | |
| 2147566 | 9A SEAL-O-RING | 1 | |
| 8C3446 | 9B VALVE-SAMPLING | 1 | |
| 3238149 | 10 STUD (M8X1.25X24.75-MM, M8X1.25X40-MM) | 2 | |
| 6V2317 | 11 BOLT (M8X1.25X30-MM) | 1 | |
| 6V5219 | 12 BOLT (M8X1.25X40-MM) | 6 | |
| 6V5220 | 13 BOLT (M8X1.25X65-MM) | 2 | |
| 8C3445 | 14 CAP-DUST | 1 | |
| 9M1974 | 15 WASHER-HARD (8.8X16X2-MM THK) | 12 | |
| 9X2099 | 16 STUD (M8X1.25X52.75-MM) | 1 |
