System And Components
481-4569 LINES GP-COOLANTPART OF 443-1506 INSTALLATION AR-ENGINE
Group No: 481-4569
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2094254 | 1 GROMMET | 4 | |
| 4616192 | 2 CABLE AS | 2 | |
| 4318746 | SLEEVE | 2 | |
| 4417501 | WIRE (49-CM) | ||
| 4619015 | CONNECTOR | 1 | |
| 9X6772 | 3 STRAP-CABLE | 1 | |
| 1349883 | 4 VALVE-BALL | 2 | |
| 3399282 | 5 CONNECTOR-HOSE | 2 | |
| 3458860 | 6 GROMMET | 1 | |
| 3718410 | 7 VALVE-BALL | 2 | |
| 3718411 | 8 VALVE AS | 2 | |
| 6V1634 | RIVET-POP | 2 | |
| 3718410 | VALVE-BALL | 1 | |
| 3718412 | HANDLE | 1 | |
| 4339114 | 9 HOSE AS | 1 | |
| 4914818 | 10 HOSE AS | 2 | |
| 4914819 | 11 HOSE AS | 1 | |
| 4914820 | 12 HOSE AS | 2 | |
| 4914822 | 13 HOSE AS | 1 | |
| 4914823 | 14 HOSE AS | 1 | |
| 4914825 | 15 COVER AS-GAUGE | 1 | |
| 4914828 | 16 GAUGE GP-SIGHT | 2 | |
| 4914829 | 17 TUBE AS | 1 | |
| 4914830 | 18 TUBE AS | 1 | |
| 4914831 | 19 TUBE AS | 1 | |
| 4914832 | 20 TUBE AS | 1 | |
| 0016449 | 21 CONNECTOR | 4 | |
| 0019440 | 22 CONNECTOR | 1 | |
| 0025743 | 23 ELBOW | 1 | |
| 0032143 | 24 ELBOW | 1 | |
| 0307942 | 25 ELBOW | 1 | |
| 0324036 | 26 FITTING | 2 | |
| 0993001 | 27 CLIP | 7 | |
| 1030892 | 28 GROMMET | 1 | |
| 1481740 | 29 ELBOW | 1 | |
| 1488324 | 30 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9874 | CONNECTOR (STRAIGHT) | 1 | |
| 1932120 | 31 GROMMET | 1 | |
| 1994673 | 32 CONNECTOR | 2 | |
| 1P4278 | 33 CLAMP-HOSE | 2 | |
| 2057299 | 34 CLIP (LOOP) | 8 | |
| 2N3378 | 35 ELBOW-FLARED | 2 | |
| 2S3440 | 36 CLAMP-HOSE | 2 | |
| 3J1907 | 37 SEAL-O-RING | 1 | |
| 3U2752 | 38 CLIP (LOOP) | 3 | |
| 4L6454 | 39 BOLT (3/8-16X1-IN) | 11 | |
| 4M5281 | 40 BOLT (1/4-20X0.75-IN) | 2 | |
| 4S6399 | 41 CONNECTOR | 2 | |
| 5P7468 | 42 CLIP (SLOT) | 2 | |
| 5P7469 | 43 CLIP (TAB) | 2 | |
| 6F7732 | 44 BUSHING-REDUCER | 1 | |
| 6K1972 | 45 ELBOW-FLARED | 2 | |
| 6V1867 | 46 CLIP (SLOT) | 1 | |
| 6V1868 | 47 CLIP (TAB) | 1 | |
| 6V4349 | 48 GROMMET | 2 | |
| 6V6782 | 49 CLIP (SLOT) | 2 | |
| 6V6783 | 50 CLIP (TAB) | 2 | |
| 6V8801 | 51 NUT (3/8-16-THD) | 1 | |
| 6V9746 | 52 SEAL-O-RING | 2 | |
| 7D8793 | 53 ELBOW-FLARED | 2 | |
| 7X0447 | 54 NUT (7/16-14-THD) | 2 | |
| 7X7902 | 55 ELBOW | 1 | |
| 8L3282 | 56 CONNECTOR | 2 | |
| 8T0083 | 57 TEE-UNION | 1 | |
| 8T4205 | 58 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4896 | 59 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 8T5360 | 60 WASHER (12X22.5X2.5-MM THK) | 4 | |
| 8T8916 | 61 BOLT (7/16-14X1.5-IN) | 2 | |
| 9B7237 | 62 BOLT (3/8-16X1.25-IN) | 1 | |
| 9X2398 | 63 ELBOW | 1 | |
| 8C3681 | 64 HOSE | ||
| 1666141 | 65 HOSE | ||
| 1415519 | 66 PIPE-BULK |
