System And Components
496-3398 PANEL GP-CONTROLS/N XPL1-UP
Group No: 496-3398
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1694481 | 1 HINGE AS | 2 | |
| 1003245 | 2 LAMP (24-VOLT) | 2 | |
| 2145790 | 3 LAMP GP (GREEN) | 1 | |
| 1435084 | BASE-LAMP | 1 | |
| 2146827 | CLIP | 1 | |
| 2146830 | HOLDER | 1 | |
| 2266446 | 4 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 2615503 | COLLAR | 1 | |
| 2286935 | 5 BLOCK-CONTACT | 3 | |
| 2661570 | 6 LOCK | 1 | |
| 3890969 | 7 ALARM GP (HORN) | 1 | |
| 4907217 | 8 LAMP AS (RED) | 1 | |
| 1435084 | BASE-LAMP | 1 | |
| 2146827 | CLIP | 1 | |
| 4963397 | 9 PANEL AS-DOOR | 1 | |
| 5P5637 | 10 SEAL (0.2-M) | ||
| 1699012 | 11 WASHER-HARD (2.7X6X0.5-MM THK) | 1 | |
| 8C6354 | 12 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1253295 | 13 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 1 | |
| 1699016 | 14 NUT (M2.5X0.45-THD) | 1 | |
| 6V9498 | 15 WASHER-HARD (3.2X7X0.5-MM THK) | 1 | |
| 1673593 | 16 STRAP | 1 | |
| 2266447 | 17 DISC (EMERGENCY STOP) | 1 |
