System And Components
479-7110 DOOR GP-ACCESSS/N XP81-UP
Group No: 479-7110
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P1991 | 1 BUTTON | 2 | |
| 8C4413 | 2 BALL JOINT | 1 | |
| 1447183 | 3 RING-RETAINING | 9 | |
| 2197350 | 4 STAY | 1 | |
| 2324944 | 5 GROMMET | 1 | |
| 2657111 | 6 WINDOW | 1 | |
| 3660081 | 7 LATCH AS | 1 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 1H3244 | LOCKWASHER | 4 | |
| 8T4244 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3660082 | 8 PAWL | 1 | |
| 2375072 | 9 SEAL (18-DM) | ||
| 4797232 | 10 DOOR AS | 1 | |
| 1428194 | RIVET | 4 | |
| 3551390 | BRACKET AS | 2 | |
| 3445674 | 11 NUT (M8X1.25-THD) | 2 | |
| 5P4116 | 12 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 2375071 | 13 SEAL (18-DM) | ||
| 4576596 | 14 GASKET | 1 |
