System And Components
463-2474 MUFFLER GPS/N KJE1-UP
Group No: 463-2474
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N7611 | 1 CAP AS-RAIN (EXHAUST) | 1 | |
| 3368526 | 2 BELLOWS | 1 | |
| 3660079 | 3 MUFFLER AS | 1 | |
| 3841259 | 4 PLATE | 2 | |
| 3841260 | 5 PLATE | 1 | |
| 3869290 | 6 GASKET | 1 | |
| 4632466 | 7 TUBE AS | 1 | |
| 4632497 | 8 TUBE AS | 1 | |
| 1757141 | 9 NUT-HEX FLANGE (M10X1.5-THD) | 12 | |
| 2473393 | 10 CLAMP AS (V-BAND) | 2 | |
| 2892492 | 11 CLAMP-MUFFLER | 1 | |
| 3383669 | 12 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 12 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 6V7673 | 14 BOLT (M12X1.75X50-MM) | 8 | |
| 6V8149 | 15 NUT (M12X1.75-THD) | 8 |
