System And Components
449-0565 TANK GP-FUELS/N KJE1-UP
Group No: 449-0565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2422082 | 1 VALVE (FUEL TANK) | 2 | |
| 2452875 | 2 VENT | 1 | |
| 4169031 | 3 PIPE AS | 2 | |
| 4204390 | 4 PIPE | 1 | |
| 4226064 | 5 SENSOR AS (FUEL LEAK) | 1 | |
| 8T4139 | 6 BOLT (M12X1.75X30-MM) | 6 | |
| 4226867 | 7 GAUGE AS-FUEL LEVEL | 1 | |
| 4235774 | GAUGE AS-FUEL LEVEL | 1 | |
| 4616415 | 8 BASE AS-FUEL TANK | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 4490566 | BASE AS | 1 | |
| 2287090 | 9 SEAL-O-RING | 1 | |
| 3B0551 | 10 PLUG-PIPE | 1 | |
| 5P1076 | 11 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 6V9830 | 12 CAP (ORFS) | 1 | |
| 6V1897 | 13 PLUG-PIPE | 2 |
