System And Components
465-1409 LINES GP-STEERINGS/N FBW1-UP
Group No: 465-1409
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9522 | 1 BAND-MARKER (YELLOW, L2) | 1 | |
| 4I9524 | 2 BAND-MARKER (BROWN, L4) | 3 | |
| 4I9525 | 3 BAND-MARKER (ORANGE, R1) | 1 | |
| 4I9526 | 4 BAND-MARKER (WHITE, R2) | 1 | |
| 4I9528 | 5 BAND-MARKER (PURPLE, R4) | 1 | |
| 4M6921 | 6 WASHER-SPRING | 4 | |
| 7K1181 | 7 STRAP-CABLE | 4 | |
| 1335813 | 8 BAND-MARKER (GRAY, P) | 1 | |
| 1457118 | 9 HOSE AS | 1 | |
| 1873774 | 10 PUMP GP-METERING (HMU) | 1 | |
| 1881814 | 11 VALVE GP-PRIORITY (MAIN)(STEERING) | 1 | |
| 1908557 | 12 HOSE AS | 1 | |
| 2413508 | 13 HOSE AS | 1 | |
| 2542649 | 14 BLOCK-MANIFOLD | 2 | |
| 4406158 | 15 HOSE AS | 1 | |
| 4407315 | 16 HOSE AS | 1 | |
| 4411149 | 17 HOSE AS | 1 | |
| 1488326 | 18 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488340 | 19 CONNECTOR AS | 5 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488361 | 20 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488364 | 21 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488395 | 22 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 1620177 | 23 PLUG AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 8T0276 | 24 BOLT (M8X1.25X45-MM) | 5 | |
| 8T4136 | 25 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T6912 | 27 BOLT (M8X1.25X50-MM) | 1 |
