System And Components
441-4756 LINES GP-PILOT -UPPER FRAME, CAB RISERS/N FB31-UP; FME1-UP
Group No: 441-4756
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1335813 | 1 BAND-MARKER (GRAY, P) | 4 | |
| 2542649 | 2 BLOCK-MANIFOLD | 1 | |
| 4502988 | 3 COVER | 1 | |
| 4502990 | 4 VALVE GP-CONTROL (HYDRAULIC CAB RISER) | 1 | |
| 1084282 | 5 BOLT-SOCKET HEAD (M10X1.5X100-MM) | 2 | |
| 1130471 | 6 HOSE AS | 1 | |
| 1237957 | 7 HOSE AS | 1 | |
| 1488336 | 8 CONNECTOR AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488354 | 9 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488367 | 10 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488378 | 11 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1556985 | 12 HOSE AS | 1 | |
| 1620177 | 13 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1989449 | 14 HOSE AS | 1 | |
| 2018756 | 15 HOSE AS | 1 | |
| 2018759 | 16 HOSE AS | 1 | |
| 2244885 | 17 HOSE AS | 1 | |
| 3445674 | 18 NUT (M8X1.25-THD) | 2 | |
| 4450588 | 19 HOSE AS | 1 | |
| 4I9521 | 20 BAND-MARKER (RED, L1) | 4 | |
| 4I9522 | 21 BAND-MARKER (YELLOW, L2) | 2 | |
| 4I9523 | 22 BAND-MARKER (BLUE, L3) | 8 | |
| 4I9524 | 23 BAND-MARKER (BROWN, L4) | 4 | |
| 4I9525 | 24 BAND-MARKER (ORANGE, R1) | 4 | |
| 4I9526 | 25 BAND-MARKER (WHITE, R2) | 4 | |
| 4I9527 | 26 BAND-MARKER (GREEN, R3) | 20 | |
| 4I9528 | 27 BAND-MARKER (PURPLE, R4) | 14 | |
| 5W1119 | 28 WASHER (9.8X18.5X1.5-MM THK) | 2 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6869 | 30 BOLT (M8X1.25X60-MM) | 2 | |
| 8T7934 | 31 WASHER-HARD (11X21X5-MM THK) | 2 | |
| 8U4744 | 32 LATCH-LOCK | 2 | |
| 1209058 | 33 HOSE AS | 2 | |
| 1301153 | 34 HOSE AS | 2 | |
| 1511948 | 35 HOSE AS | 2 | |
| 2259417 | 36 HOSE AS | 2 | |
| 7K1181 | 37 STRAP-CABLE | 6 |
