System And Components
465-7471 GENERATOR GPS/N TXR1-UP
Group No: 465-7471
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2414577 | 1 EYE-LIFTING | 1 | |
| 2414579 | 2 SCREEN | 1 | |
| 2414587 | 3 KIT-RING | 1 | |
| 2414589 | 4 PANEL-TERMINAL BOX | 1 | |
| 2414591 | 5 SCREEN-AIR INLET | 1 | |
| 2414594 | 6 COVER | 1 | |
| 2414607 | 7 SUPPORT | 1 | |
| 2414610 | 8 SUPPORT | 1 | |
| 2414612 | 9 SUPPORT | 2 | |
| 2414614 | 10 HUB | 1 | |
| 2414616 | 11 DISC | 1 | |
| 2414618 | 12 SHIM (2-MM THK) | 7 | |
| 2414624 | 13 SUPPORT | 1 | |
| 2414627 | 14 PANEL-ACCESS | 1 | |
| 2414628 | 15 PANEL-ACCESS | 1 | |
| 2414629 | 16 MOUNT AS-RESILIENT | 1 | |
| 5C2874 | NUT (M5X0.8-THD) | 8 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 0960192 | LOCKWASHER | 8 | |
| 2544235 | MOUNT | 4 | |
| 2422982 | 17 PANEL-ACCESS | 1 | |
| 2435220 | 18 BEARING | 1 | |
| 2703027 | 21 BRACKET | 1 | |
| 3450793 | 22 FAN | 1 | |
| 3758208 | 24 COVER-BOX | 1 | |
| 4374483 | 26 PANEL-ACCESS | 1 | |
| 4481092 | 27 CONTROL GP-ELECTRONIC (EXCITATION MODULE 10) | 1 | |
| 2354451 | 28 BOLT-FLANGE HEAD (M6X1X16-MM) | 28 | |
| 8C8451 | 29 BOLT (M6X1X40-MM) | 2 | |
| 8T0226 | 30 BOLT (M14X2X45-MM) | 6 | |
| 8T4140 | 31 BOLT (M16X2X60-MM) | 8 | |
| 8T4194 | 32 BOLT (M12X1.75X50-MM) | 4 | |
| 2435380 | 33 CAP | 1 | |
| 2414595 | CAP-BEARING | 1 | |
| 2414605 | ARMATURE | 1 | |
| 2414606 | SUPPORT-DIODE | 1 | |
| 2414619 | DIODE AS | 1 | |
| 2423797 | EXCITER | 1 | |
| 4374481 | VARISTOR | 1 | |
| 2414615 | KEY-SQUARE | 1 | |
| 2414576 | DISC | 1 | |
| 1516283 | BOLT-SOCKET HEAD (M6X1X70-MM) | 4 |
