System And Components
521-3680 PANEL GP-ELECTRONICS/N CF91-UP; CJ91-UP
Group No: 521-3680
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 6 | |
| 1434456 | 2 INSULATOR | 2 | |
| 2039007 | 3 NUT (1-1/2-18-THD) | 1 | |
| 2395374 | 4 CONNECTOR (CONDUIT) | 2 | |
| 2413114 | 5 HORN | 1 | |
| 2642523 | 6 CONNECTOR | 2 | |
| 2681418 | 7 PLATE-TERMINAL | 1 | |
| 2702679 | 8 LOCKWASHER | 1 | |
| 3776488 | 9 HANDLE | 1 | |
| 4465618 | 10 SWITCH AS (EMERGENCY STOP) | 1 | |
| 4557867 | 11 CAP AS | 1 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 4775095 | 12 PLATE-COVER | 1 | |
| 4775099 | 13 BAR | 1 | |
| 4799628 | 14 CONTROLLER | 1 | |
| 4804407 | 15 MOUNTING GP-POWER MODULE | 1 | |
| 8T4138 | BOLT (M6X1X20-MM) | 4 | |
| 9X8256 | WASHER (6.6X12X2-MM THK) | 4 | |
| 4805392 | 16 HARNESS AS-POWER | 1 | |
| 3S2093 | STRAP-CABLE | 7 | |
| 5P1475 | TERMINAL-FORK (14-GA TO 16-GA, NO. 8 SCREW) | 3 | |
| 1093038 | END-WIRE (16-GA) | 2 | |
| 4807107 | 17 MOUNTING GP-POWER MODULE | 1 | |
| 8T4189 | BOLT (M8X1.25X20-MM) | 8 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 4921937 | 18 FILM-IDENTIFICATION (START)(STARTER) | 1 | |
| 4921938 | 19 FILM-IDENTIFICATION (120-VOLT)(SOCKET) | 1 | |
| 4921940 | 20 FILM-IDENTIFICATION (SOCKET RECEPTACLE) | 1 | |
| 4951284 | 21 CABLE GP-GENERATOR GROUND | 1 | |
| 4954701 | 22 HARNESS AS-PANEL | 1 | |
| 5138002 | 23 FILM-IDENTIFICATION (DISTRIBUTION PANEL) | 1 | |
| 5147933 | 24 BRACKET AS | 1 | |
| 5194666 | 26 PANEL AS | 1 | |
| 5194668 | 27 FRAME AS | 1 | |
| 5194674 | 28 PANEL GP-ELECTRONIC | 1 | |
| 5194697 | 29 WIRE AS | 1 | |
| 5204467 | 30 WIRING GP-PANEL | 1 | |
| 5204468 | 31 PANEL | 1 | |
| 5204469 | 32 PLATE | 1 | |
| 5213672 | 33 PANEL GP-ELECTRONIC | 1 | |
| 5213675 | 34 PANEL GP-ELECTRONIC | 1 | |
| 5213683 | 35 WIRING GP-PANEL | 1 | |
| 5213685 | 36 CIRCUIT BREAKER GP | 1 | |
| 5214468 | 37 CABLE GP-GENERATOR GROUND | 1 | |
| 5242248 | 38 HEATER GP-JACKET WATER | 1 | |
| 0966166 | 39 WASHER-HARD (4.5X9X1-MM THK) | 5 | |
| 1313540 | 40 LOCKNUT (M8X1.25-THD) | 2 | |
| 1325789 | 41 CLIP (LADDER) | 4 | |
| 1339379 | 42 GROMMET | 1 | |
| 1921329 | 43 BOLT-SPECIAL | 4 | |
| 1989706 | 44 SCREW-TRUSS HEAD (M5X0.8X16-MM) | 9 | |
| 2253109 | 45 SCREW-TRUSS HEAD (M4X0.7X14-MM) | 3 | |
| 2395375 | 46 NUT (M32X1.5-THD) | 2 | |
| 2664324 | 47 SWITCH-LIMIT (TERMINAL BOX) | 1 | |
| 2666450 | 48 TERMINAL | 2 | |
| 2679125 | 49 SOCKET (125-VOLT, 30-AMPERE) | 1 | |
| 3445675 | 50 NUT (M10X1.5-THD) | 5 | |
| 4952523 | 51 FILM-IDENTIFICATION (CIRCUIT BREAKER) | 1 | |
| 5C2890 | 52 NUT (M6X1-THD) | 1 | |
| 5P4116 | 53 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 6V8931 | 54 SCREW-WASHER HEAD (M6X1X16-MM) | 4 | |
| 8C9660 | 55 WASHER (4.6X7.9X0.8-MM THK) | 2 | |
| 8T0328 | 56 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T4121 | 57 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4136 | 58 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4138 | 59 BOLT (M6X1X20-MM) | 13 | |
| 8T4171 | 60 BOLT (M6X1X12-MM) | 3 | |
| 8T4189 | 61 BOLT (M8X1.25X20-MM) | 17 | |
| 8T4195 | 62 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4199 | 63 BOLT (M8X1.25X12-MM) | 4 | |
| 8T4200 | 64 BOLT (M8X1.25X16-MM) | 3 | |
| 8T4205 | 65 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T4224 | 66 WASHER-HARD (8.8X16X2-MM THK) | 15 | |
| 8T7500 | 67 SCREW-MACHINE (M4X0.7X35-MM) | 2 | |
| 9X2038 | 68 WASHER (7X19X2-MM THK) | 6 | |
| 9X8256 | 69 WASHER (6.6X12X2-MM THK) | 6 | |
| 3694505 | 70 CONDUIT (13-CM) | ||
| 2352765 | 71 CONDUIT-FLEXIBLE (27.6-MM ID)(23-CM) | ||
| 5P5902 | 72 SEAL (0.43-M EACH) | ||
| 3E6600 | 73 SEAL (88-CM) | ||
| 3E6600 | 73A SEAL (38.6-CM) | ||
| 3E6600 | 73B SEAL (28.6-CM) | ||
| 3E6600 | 73C SEAL (32.6-CM) | ||
| 3E6600 | 73D SEAL (60-CM) | ||
| 3E6600 | 73E SEAL (33-CM) | ||
| 3E6600 | 73F SEAL (55-CM) | ||
| 0996418 | 74 NUT (M6X1-THD) | 4 | |
| 4226062 | 75 WIRE AS | 2 | |
| 2N3477 | 76 SCREW-MACHINE (6-32X1.25-IN) | 2 | |
| 4B2041 | 77 NUT (6-32-THD) | 2 | |
| 8T4970 | 78 BOLT (M6X1X14-MM) | 2 |
