System And Components
293-2874 FILTER GP-ENGINE OILFOR USE WITH MARINE RIGHT HAND SERVICE
Group No: 293-2874
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R1808 | 1 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 2 | |
| 2P3760 | 2 GASKET | 1 | |
| 2P3761 | 3 COVER | 1 | |
| 2P4301 | 4 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4303 | 5 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4305 | 6 GASKET | 4 | |
| 4N7082 | 7 SHIELD-OIL FILTER | 2 | |
| 4N8150 | 8 SPRING | 1 | |
| 6N0821 | 9 HOUSING | 1 | |
| 6N0824 | 10 GASKET | 1 | |
| 8C3445 | 11 CAP-DUST | 1 | |
| 8C3446 | 12 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 9M0853 | 13 PLUNGER-VALVE | 1 | |
| 2348937 | 14 SEAL-INTEGRAL | 1 | |
| 2395571 | 15 SEAL-INTEGRAL | 1 | |
| 2932875 | 16 COVER | 1 | |
| 2932882 | 17 BONNET | 1 | |
| 2932883 | 18 TUBE AS | 1 | |
| 2932884 | 19 ELBOW | 1 | |
| 2932885 | 20 TUBE AS | 1 | |
| 2932886 | 21 FLANGE | 1 | |
| 5166017 | 22 COVER | 1 | |
| 0L2070 | 23 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1571 | 24 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 25 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1590 | 26 BOLT (3/8-16X2-IN) | 7 | |
| 0T0102 | 27 BOLT (3/8-16X0.625-IN) | 1 | |
| 0T0573 | 28 BOLT (3/8-16X2.75-IN) | 2 | |
| 1090078 | 29 SEAL-O-RING | 4 | |
| 1C2251 | 30 BOLT (3/8-16X1.87-IN) | 1 | |
| 2M1538 | 31 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 4B5271 | 32 WASHER (25.5X11.2X2-MM THK) | 1 | |
| 5B2638 | 33 BOLT (3/8-16X5.25-IN) | 4 | |
| 5M2894 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 33 | |
| 6V5048 | 35 SEAL-O-RING | 3 | |
| 7F9090 | 36 SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 9S4182 | 37 PLUG (7/16-20-THD) | 2 | |
| 9S8752 | 38 NUT-FULL (3/8-16-THD) | 16 | |
| 9X6458 | 39 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 3072671 | 40 PLUG AS | 2 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 |
