394-3719 ENCLOSURE GP-GENERATORS/N TXB1-UP

Group No: 394-3719
Part NumberPart NameQty
8C44131 BALL JOINT1
14269502 HINGE AS10
14281943 RIVET10
14471834 RING-RETAINING24
21973505 STAY1
23544516 BOLT-FLANGE HEAD (M6X1X16-MM)37
23750687 GROMMET2
25910279 STOP-DOOR4
263075710 STOP-DOOR4
307959811 COVER-ACCESS1
352297912 LATCH AS5
5C2890NUT (M6X1-THD)4
1H3244LOCKWASHER4
1608499NUT (M12X1.5-THD)2
3260612WASHER-TAB2
366008213 PAWL5
366008314 BRACKET AS5
381618915 DOOR AS-ACCESS1
1428194RIVET4
1428212BRACKET2
381866416 ENCLOSURE GP-GENERATOR1
381866917 INSULATION AS1
384466918 DOOR AS-ACCESS1
444030019 BRACKET2
1H333820 LOCKWASHER10
142490121 SCREW (M10X1.5X20-MM)54
5C289022 NUT (M6X1-THD)33
5C726123 NUT (M8X1.25-THD)2
5C955324 BOLT (M6X1X16-MM)4
8T412125 WASHER-HARD (11X21X2.5-MM THK)80
8T413326 NUT (M10X1.5-THD)40
8T413627 BOLT (M10X1.5X25-MM)40
8T422428 WASHER-HARD (8.8X16X2-MM THK)2
8T497129 BOLT (M6X1X30-MM)4
9X825630 WASHER (6.6X12X2-MM THK)28
5P592431 SEAL (8.68-M)
398736732 SEAL (33.4-DM)
398736732A SEAL (35.5-DM)
398736732B SEAL (31.2-DM)
256046633 NUT (M10X1.5-THD)4
9Y706634 WASHER (12.7X18X3-MM THK)8
8T938835 BOLT (M10X1.5X25-MM)4
2566238CABLE AS5
5W9297TERMINAL2
