System And Components
488-2418 FILTER GP-ENGINE OIL -RHAN ATTACHMENT
Group No: 488-2418
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R1808 | 1 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 4 | |
| 1R0716 | FILTER AS-ENGINE OIL (STANDARD EFFICIENCY) | 4 | |
| 2P3761 | 2 COVER | 2 | |
| 2P4301 | 3 BASE AS-OIL FILTER | 2 | |
| 2P4303 | 4 BASE AS-OIL FILTER | 2 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 4H9756 | 5 LEVER-RELEASE CONTROL | 1 | |
| 4N7082 | 6 SHIELD-OIL FILTER | 4 | |
| 4N8150 | 7 SPRING | 2 | |
| 5L5709 | 8 CONNECTOR-SHIELD | 1 | |
| 6N0824 | 9 GASKET | 1 | |
| 6N1258 | 10 HOUSING | 1 | |
| 6N1259 | 11 POINTER | 1 | |
| 7N0912 | 12 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 7N0911 | VALVE AS (ENGINE OIL) | 1 | |
| 3F9190 | PIN | 1 | |
| 7N0914 | 13 DETENT AS | 1 | |
| 6J8356 | SPRING | 2 | |
| 6N4204 | PIN | 2 | |
| 6N4205 | PLATE | 1 | |
| 7N0913 | RING | 1 | |
| 8F8833 | PIN | 1 | |
| 9M0853 | 14 PLUNGER-VALVE | 2 | |
| 2395571 | 15 SEAL-INTEGRAL | 1 | |
| 2433384 | 16 BRACKET | 1 | |
| 2888580 | 17 CLAMP-FUEL LINE | 1 | |
| 2888581 | 18 CLAMP-FUEL LINE | 1 | |
| 2932875 | 19 COVER | 1 | |
| 2932882 | 20 BONNET | 1 | |
| 2932884 | 21 ELBOW | 1 | |
| 2932886 | 22 FLANGE | 1 | |
| 2932889 | 23 TUBE AS | 1 | |
| 2932890 | 24 TUBE AS | 1 | |
| 2938627 | 25 TUBE AS | 1 | |
| 2938628 | 26 TUBE AS | 1 | |
| 2939385 | 27 BRACKET | 1 | |
| 3072671 | 28 PLUG AS | 2 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3593527 | 29 FILM-IDENTIFICATION (OIL FILTER DUPLEX VALVE) | 1 | |
| 3855772 | 30 ELBOW AS | 2 | |
| 6V8628 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 5166017 | 31 COVER | 1 | |
| 0815622 | 32 ADAPTER | 2 | |
| 0L1351 | 33 BOLT (3/8-16X0.875-IN) | 2 | |
| 0L2070 | 34 BOLT (3/8-16X2.25-IN) | 2 | |
| 1653931 | 35 BOLT (3/8-16X1.75-IN) | 12 | |
| 0S1588 | 36 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1590 | 37 BOLT (3/8-16X2-IN) | 6 | |
| 0S1594 | 38 BOLT (3/8-16X1-IN) | 1 | |
| 0T0573 | 39 BOLT (3/8-16X2.75-IN) | 2 | |
| 1090078 | 40 SEAL-O-RING | 4 | |
| 1665396 | 41 SCREW-WASHER HEAD (1/4-20X0.5-IN) | 1 | |
| 1A2029 | 42 BOLT (3/8-16X1.125-IN) | 1 | |
| 1B8704 | 43 KEY-WOODRUFF | 2 | |
| 1C2251 | 44 BOLT (3/8-16X1.87-IN) | 1 | |
| 2348937 | 45 SEAL-INTEGRAL | 1 | |
| 2M1538 | 46 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 2P3760 | 47 GASKET | 2 | |
| 2P4305 | 48 GASKET | 6 | |
| 3218649 | 49 VALVE AS-FLUID SAMPLING (ENGINE OIL) | 1 | |
| 8C3446 | VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3P0656 | 50 SEAL-O-RING | 1 | |
| 4J5477 | 51 SEAL-O-RING | 2 | |
| 5B2638 | 52 BOLT (3/8-16X5.25-IN) | 4 | |
| 5M2894 | 53 WASHER-HARD (10.2X18.5X2.5-MM THK) | 53 | |
| 5P7813 | 54 SEAL-O-RING | 2 | |
| 6V8801 | 55 NUT (3/8-16-THD) | 2 | |
| 7F9090 | 56 SCREW-DRIVE (NO 8X3/8-IN) | 8 | |
| 7X0290 | 57 BOLT (3/8-16X3.5-IN) | 2 | |
| 8C3445 | 58 CAP-DUST | 1 | |
| 8M2772 | 59 CLIP (LOOP) | 1 | |
| 8T4896 | 60 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9S8752 | 61 NUT-FULL (3/8-16-THD) | 28 | |
| 9X6458 | 62 WASHER-HARD (10.2X22.5X3-MM THK) | 10 |
