528-9925 ENCLOSURE GP-GENERATORS/N T331-UP

Group No: 528-9925
Part NumberPart NameQty
39049171 PLATE (CLOSING)1
39324452 PANEL AS2
39324463 PANEL AS2
1428194RIVET4
1428212BRACKET2
39324474 PANEL2
39324485 PANEL AS (ROOF)1
39324496 PANEL AS1
39324507 PANEL AS1
39324518 PANEL AS6
3E4304INSERT-THREADED (M6X1-THD)2
39324529 PANEL AS6
393245410 PANEL AS (RH)1
3E4304INSERT-THREADED (M6X1-THD)2
2380029INSERT-THREADED (M10X1.5-THD)5
393245611 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)2
2380029INSERT-THREADED (M10X1.5-THD)17
393246312 PANEL AS (RH)1
393246413 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)1
1428194RIVET4
1428212BRACKET2
2380029INSERT-THREADED (M10X1.5-THD)9
393247514 PANEL AS3
393247715 PANEL AS1
1338073HANDHOLD1
393247816 PANEL AS2
3E4304INSERT-THREADED (M6X1-THD)2
399131419 PANEL AS2
453212020 PANEL AS1
453212121 PANEL AS1
6V9632NUT-WELD (M6X1-THD)4
453212322 PANEL AS (RH)1
6V9632NUT-WELD (M6X1-THD)3
453212423 PANEL AS1
453212524 PANEL AS (LH)1
6V9632NUT-WELD (M6X1-THD)3
453212625 PANEL AS (RH)1
453212726 PANEL AS (CENTER)1
453212827 PANEL AS (LH)1
460904128 DOOR GP-ACCESS1
463266629 PANEL AS1
463267330 PANEL AS-ROOF1
1428194RIVET6
463267431 PANEL AS2
463301032 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)6
463304233 PANEL AS-SIDE (LH)(LH)1
3E4304INSERT-THREADED (M6X1-THD)2
463304334 PANEL AS-SIDE (RH)(RH)1
463304535 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)6
463307836 DOOR AS2
