Assembly
100%

559-7194 BOX GP-CONTROLS/N C2F1-UP

Group No: 559-7194
Part NumberPart NameQty
09659621 WASHER-HARD (3.4X7X0.8-MM THK)2
8T42052 WASHER-HARD (7.2X14.5X2-MM THK)4
8T02653 SCREW-MACHINE (M3X0.5X16-MM)2
26242374 RESISTOR2
26242555 BLOCK-TERMINAL3
26246226 FUSE (10-AMPERE)2
26246237 FUSE (10-AMPERE)3
26246368 SWITCH (OPERATOR)1
26246379 BLOCK-CONTACT3
262463810 BLOCK-CONTACT2
8T032811 WASHER-HARD (5.5X10X1-MM THK)4
267727912 GROMMET2
267728013 GROMMET2
317008415 GUIDE (WIRE)2
317082616 BRACKET-END2
370829817 CIRCUIT BREAKER (240-VOLT)(240V)1
370829918 CIRCUIT BREAKER (240-VOLT)(240V)1
370830219 RELAY (24-VOLT)(24-VOLT, 35-AMPERE)2
374430220 BLOCK-TERMINAL54
393081721 SWITCH-SELECTOR (LIGHTING)2
423680322 TERMINAL2
424296523 HOLDER-FUSE5
424733024 RAIL2
424732925 COVER-END5
559719726 BOX GP-CONTROL1
5C831227 NUT (M4X0.7-THD)2
6V967328 SCREW-MACHINE (M5X0.8X12-MM)4
6A908329 SCREW-MACHINE (M6X1X15-MM)4
569108730 FILM-INFORMATION (GENERATOR CONTROL PANEL)1
570336231 FILM-IDENTIFICATION (PANEL)1
9X399432 PLUG2
8T412133 WASHER-HARD (11X21X2.5-MM THK)12
8T413634 BOLT (M10X1.5X25-MM)12
6B454035 NUT (4-40-THD)4
6B454236 LOCKWASHER4
6V248037 SCREW (4-40X0.5-IN)4
5695907GROMMET1
5708252TERMINAL10
5695884TERMINAL5
5708421FILM-IDENTIFICATION1
