System And Components
357-3624 DRIVE GP-FAN -BELTS/N PRH1-UP
Group No: 357-3624
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N2538 | 1 BRACKET-FAN ADJUSTMENT | 1 | |
| 6N2547 | 2 ADAPTER-FAN BRACKET | 1 | |
| 7E4808 | 3 PLATE | 1 | |
| 2721596 | 4 ADAPTER AS | 1 | |
| 3102199 | 5 V-BELT SET (INCLUDES 4-BELTS)(FAN DRIVE) | 1 | |
| 4446555 | 6 BRACKET AS | 1 | |
| 4N0684 | DOWEL | 1 | |
| 3330773 | 7 SPACER-SPECIAL (39X47.5X18-MM THK) | 1 | |
| 3330774 | 8 HUB | 1 | |
| 3330776 | 9 SPACER-SPECIAL | 1 | |
| 3330777 | 10 ADAPTER | 1 | |
| 3332408 | 11 BALL BEARING | 2 | |
| 3464803 | 12 PULLEY-FAN (4-GROOVE) | 1 | |
| 1180275 | 13 WASHER (13.5X32X8-MM THK) | 4 | |
| 1A2029 | 14 BOLT (3/8-16X1.125-IN) | 2 | |
| 1Y3844 | 15 STUD-TAPERLOCK (1/2-13-THD) | 4 | |
| 2M2488 | 16 STUD-TAPERLOCK (3/8-16X3.59-IN) | 6 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6H3956 | 18 PIN | 1 | |
| 6V8188 | 19 NUT (1/2-13-THD) | 4 | |
| 6V8801 | 20 NUT (3/8-16-THD) | 1 | |
| 9L5595 | 21 BOLT (3/8-16X5-IN) | 1 | |
| 9S8752 | 22 NUT-FULL (3/8-16-THD) | 6 | |
| 9X8874 | 23 BOLT (1/2-13X3-IN) | 1 | |
| 4206942 | 24 SPACER (40.4X49X5-MM THK) | 1 |
