System And Components
504-3171 LINES GP-DIESEL EXHAUST FLUIDS/N NGH1-UP
Group No: 504-3171
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1875073 | 1 CLAMP | 1 | |
| 2066876 | 2 CAP-TUBE | 1 | |
| 3650162 | 3 CONNECTOR-SPECIAL | 1 | |
| 3989445 | 4 PLATE AS | 1 | |
| 3989448 | 5 MANIFOLD | 1 | |
| 3989449 | 6 CAP | 1 | |
| 4288808 | 7 CLAMP-HOSE | 1 | |
| 4996599 | 8 HOSE (COOLANT) | 1 | |
| 5043172 | 9 HOSE (COOLANT) | 1 | |
| 5065802 | 10 HOSE AS | 1 | |
| 4650580 | 11 HOSE (COOLANT) | 1 | |
| 1053487 | 12 BOLT-SOCKET HEAD (M6X1X20-MM) | 3 | |
| 1138694 | 13 BOLT (M6X1X20-MM) | 6 | |
| 1246257 | 14 CLAMP-HOSE | 5 | |
| 1620177 | 15 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1733993 | 16 PLUG AS | 1 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 1984775 | 17 WASHER-HARD (6.6X15X6-MM THK) | 2 | |
| 1H1023 | 18 SEAL-O-RING | 1 | |
| 2354451 | 19 BOLT-FLANGE HEAD (M6X1X16-MM) | 2 | |
| 2606671 | 20 BOLT (M6X1X12-MM) | 1 | |
| 3J1907 | 21 SEAL-O-RING | 1 | |
| 7X2503 | 22 CLIP | 4 | |
| 5065812 | 23 HOSE AS | 1 |
