Assembly
100%

526-0672 INSTRUMENT GPS/N NGH1-UP

Group No: 526-0672
Part NumberPart NameQty
5P85001 KEY (CORPORATE)1
10825152 COVER-TERMINAL2
18931583 SUPPRESSOR-ARC1
20390074 NUT (1-1/2-18-THD)1
22673005 CIRCUIT BREAKER AS (25-AMPERE)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
24183676 SWITCH AS-MAGNETIC (12-VOLT)1
4F2294NUT-JAM (5/16-24-THD)2
8T8730SOCKET-CONNECTOR (16-GA TO 20-GA)2
1552270KIT-CONNECTING PLUG (2-PIN)1
25527527 SWITCH GP-START (IGNITION)1
26037338 CIRCUIT BREAKER AS (5-AMPERE)1
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
27026799 LOCKWASHER1
340729810 CAP AS-PROTECTION1
387429911 BOX AS-INSTRUMENT1
453992312 RELAY AS (12-VOLT)(12V)2
487846213 MODULE GP-KEYPAD1
525902814 FILM-IDENTIFICATION1
526069015 HARNESS AS-PANEL1
526069116 PLATE1
526070917 DISPLAY GP-MONITOR1
5260848SOFTWARE GP-MONITOR1
526397918 BRACKET AS1
130530019 CLIP2
211005220 NUT (1-11/16-18-THD)1
310067421 LOCKWASHER1
3S209322 STRAP-CABLE4
6T364423 CIRCUIT BREAKER AS (20-AMPERE)3
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
6T364524 CIRCUIT BREAKER GP (60-AMPERE)1
6V8378NUT (10-32-THD)2
8F1434LOCKWASHER2
8T0328WASHER-HARD (5.5X10X1-MM THK)2
8T413825 BOLT (M6X1X20-MM)2
8T422426 WASHER-HARD (8.8X16X2-MM THK)2
8T497027 BOLT (M6X1X14-MM)6
9X204428 SCREW-TRUSS HEAD (M6X1X16-MM)4
9X616529 WASHER (6.5X22X2.5-MM THK)2
9X825630 WASHER (6.6X12X2-MM THK)6
9X848631 SCREW-MACHINE (8-32X0.75-IN)12
