System And Components
255-9246 LINES GP-WATERS/N TXH1-UP
Group No: 255-9246
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S9643 | 1 SEAL-LIP TYPE (WATER TEMPERATURE REGULATOR) | 2 | |
| 7C0145 | 2 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 2477133 | 3 REGULATOR-WATER TEMPERATURE (98-DEG C)(COOLANT) | 2 | |
| 1250434 | 4 SEAL-INTEGRAL | 1 | |
| 1264935 | 5 SEAL-INTEGRAL | 1 | |
| 3411429 | 6 SEAL (TEMPERATURE REGULATOR HOUSING) | 1 | |
| 1663501 | 7 PIPE | 1 | |
| 2624167 | 8 BONNET-OUTLET | 1 | |
| 2278851 | 9 MANIFOLD-HOUSING | 1 | |
| 2278852 | 10 COVER-WATER PUMP | 1 | |
| 2292282 | 11 BONNET-OIL COOLER | 1 | |
| 2361687 | 12 HOUSING-REGULATOR | 1 | |
| 0L1352 | 13 BOLT (3/8-16X3.25-IN) | 1 | |
| 0S1588 | 14 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 2 | |
| 1090077 | 17 SEAL-O-RING | 2 | |
| 1674407 | 18 SEAL-O-RING | 1 | |
| 1714358 | 19 SEAL-O-RING | 2 | |
| 4F0411 | 24 BOLT (3/8-16X6.5-IN) | 1 | |
| 3535141 | 25 PLUG AS | 1 | |
| 9S8009 | PLUG-O-RING | 1 | |
| 2918145 | SEAL-O-RING | 1 | |
| 3535124 | 28 PLUG AS | 2 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3535126 | 29 PLUG AS | 6 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3535140 | 30 PLUG AS | 2 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 9S8008 | PLUG (1-1/16-12-THD) | 1 |
