Assembly
100%

577-6375 WIRING GP-GENERATOR -ENGINE HARNESSS/N S371-UP

Group No: 577-6375
Part NumberPart NameQty
3S20931 STRAP-CABLE19
44907602 PLUG-CAP1
23544513 BOLT-FLANGE HEAD (M6X1X16-MM)4
8C96604 WASHER (4.6X7.9X0.8-MM THK)1
32933565 NUT (M12X1.75-THD)1
56961486 PANEL GP-CONTROL1
57257957 HARNESS AS-ENGINE1
57487438 MODULE-CONTROL1
1H43939 LOCKWASHER1
4P758110 CLIP (LADDER)1
5C289011 NUT (M6X1-THD)8
5C831212 NUT (M4X0.7-THD)1
8C635413 CAP-RECEPTACLE (ET CONNECTOR)1
8T412114 WASHER-HARD (11X21X2.5-MM THK)7
8T413915 BOLT (M12X1.75X30-MM)1
8T419516 BOLT (M10X1.5X30-MM)7
8T422317 WASHER-HARD (13.5X25.5X3-MM THK)2
9D376718 PLUG-BUTTON4
9X825619 WASHER (6.6X12X2-MM THK)8
239698620 PLATE-SERIAL NUMBER (MACHINE)1
349680821 MOUNT5
