Assembly
100%

449-0712 ENCLOSURE GP-GENERATORS/N RZ91-UP

Group No: 449-0712
Part NumberPart NameQty
39324511 PANEL AS4
3E4304INSERT-THREADED (M6X1-THD)2
39324522 PANEL AS4
39324583 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)9
39324674 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)3
6V9632NUT-WELD (M6X1-THD)2
2380029INSERT-THREADED (M10X1.5-THD)6
39324745 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)3
2380029INSERT-THREADED (M10X1.5-THD)6
39324756 PANEL AS3
1338073HANDHOLD1
41620687 PANEL1
41620698 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
41620709 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
416207110 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)10
416207611 DOOR AS4
1428194RIVET4
1428212BRACKET2
449052312 PANEL1
2380029INSERT-THREADED (M10X1.5-THD)6
449053013 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)1
2380029INSERT-THREADED (M10X1.5-THD)10
449053114 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)1
2380029INSERT-THREADED (M10X1.5-THD)4
449054215 PANEL AS1
449065216 GUARD1
449071317 PANEL AS2
3E4304INSERT-THREADED (M6X1-THD)2
1428194RIVET8
1428212BRACKET4
2380029INSERT-THREADED (M10X1.5-THD)8
449071518 PANEL1
449071619 PANEL1
2380029INSERT-THREADED (M10X1.5-THD)6
449071720 PANEL1
