Assembly
100%

460-6152 PANEL GP-ENCLOSURES/N RZ91-UP

Group No: 460-6152
Part NumberPart NameQty
14471831 RING-RETAINING18
39324512 PANEL AS2
3E4304INSERT-THREADED (M6X1-THD)2
39324523 PANEL AS2
39324564 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)2
2380029INSERT-THREADED (M10X1.5-THD)17
39324745 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)5
2380029INSERT-THREADED (M10X1.5-THD)6
39324776 PANEL AS1
1338073HANDHOLD1
44905147 PANEL AS1
3E4304INSERT-THREADED (M6X1-THD)2
1428194RIVET8
1428212BRACKET4
2380029INSERT-THREADED (M10X1.5-THD)8
44905318 PANEL AS (LH)1
3E4304INSERT-THREADED (M6X1-THD)1
2380029INSERT-THREADED (M10X1.5-THD)9
09964189 NUT (M6X1-THD)8
142489910 LOCKWASHER12
142490111 SCREW (M10X1.5X20-MM)12
338366912 BOLT-FLANGE HEAD (M10X1.5X30-MM)23
340153013 BOLT-FLANGE HEAD (M6X1X18-MM)10
