585-5475 WIRING GP-CAB RISERS/N NTR1-UP

Group No: 585-5475

Part Number	Part Name	Qty
8T4191	1 BOLT (M10X1.5X16-MM)	1
8T4172	2 BOLT (M10X1.5X80-MM)	8
3S2093	3 STRAP-CABLE	1
8T4121	4 WASHER-HARD (11X21X2.5-MM THK)	26
8T4136	5 BOLT (M10X1.5X25-MM)	5
8T4171	6 BOLT (M6X1X12-MM)	4
9X2042	7 SCREW-TRUSS HEAD (M6X1X12-MM)	2
9X8256	8 WASHER (6.6X12X2-MM THK)	4
2667379	9 STRAP-CABLE	1
3648334	10 PLATE AS	1
6V6716	RIVET-TRUSS HEAD	2
1091645	CLIP	1
4841451	11 CLIP	5
4841454	12 CLIP-RETAINING	4
4841456	13 STRAP-CABLE	14
4922010	14 PANEL AS	1
5065911	15 LOCK-CONNECTOR	2
5244506	16 BRACKET AS	1
6V9632	NUT-WELD (M6X1-THD)	2
8T3490	NUT-WELD (M10X1.5-THD)	1
5604083	17 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
5766849	18 HARNESS AS-CAB (PRODUCT LINK 243, 083)	1
5801286	19 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
8T3612	NUT-WELD (M8X1.25-THD)	4
5855484	20 HARNESS AS-CAB RISER	1
5855673	21 HARNESS AS-CAB RISER	1
5855674	22 CABLE AS	1
1968876	BRAID (BLACK, ONE GOLD STRAND)(264-CM)
3280111	PIN-CONNECTOR	1
3245824	PLUG AS-CONNECTOR (1-PIN)	1
3245685	RECEPTACLE AS-CONNECTOR (1-PIN)	1
3245825	SOCKET-CONNECTOR (4-GA)	1
5855675	23 CABLE AS	1
2813395	PLUG AS-CONNECTOR (12-PIN)	1
8T8737	PLUG-SEAL	16
2472694	RECEPTACLE AS-CONNECTOR (12-PIN)	1
8T8730	SOCKET-CONNECTOR (16-GA TO 20-GA)	4
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	4
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	4
5855680	24 GROMMET	5
5855681	25 BRACKET	3
5855685	26 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	7
8T3612	NUT-WELD (M8X1.25-THD)	4
5855687	27 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
8T3612	NUT-WELD (M8X1.25-THD)	1
8Y3795	BOSS (M10X1.5X40-MM)	2
5862226	28 BRACKET	2
5862228	29 BRACKET	2
5863059	30 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
7K1181	31 STRAP-CABLE	15
8T4137	32 BOLT (M10X1.5X20-MM)	10
8T4178	33 BOLT (M10X1.5X90-MM)	2
9R7941	34 SOCKET AS	1
9R7980	COVER	1
