System And Components
225-8203 ACCUMULATOR & MTG GP-HYDRAULICS/N 9PS484-484; 9PS487-487; 9PS490-490; 9PS493-493; 9PS495-496; 9PS498-498; 9PS501-503; 9PS505-505; 9PS507-516; 9PS518-521; 9PS523-UP
Group No: 225-8203
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8U7333 | 1 FITTING | 2 | |
| 1148908 | 2 CLAMP | 6 | |
| 1188985 | 3 NUT-CLAMP | 4 | |
| 1383394 | 4 HOSE AS | 1 | |
| 1457166 | 5 VALVE GP-MANUAL (BOOM LOWERING CONTROL) | 1 | |
| 1521267 | 6 ELBOW | 1 | |
| 1875501 | 7 SPACER | 1 | |
| 1905287 | 8 ORIFICE | 1 | |
| 1911381 | 9 ADAPTER | 4 | |
| 1946989 | 10 ORIFICE | 2 | |
| 2172957 | 11 BRACKET AS | 3 | |
| 2172959 | 12 BRACKET AS | 1 | |
| 2253394 | 13 ACCUMULATOR GP-HYDRAULIC (CHARGED) | 4 | |
| 2262188 | 14 BRACKET AS | 1 | |
| 2263713 | 15 HOSE AS | 2 | |
| 1083819 | 16 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 4 | |
| 1171805 | 17 CLAMP-SINGLE | 4 | |
| 1293178 | 18 LOCKNUT (M6X1-THD) | 2 | |
| 1293181 | 19 BOLT-SOCKET HEAD (M10X1.5X55-MM) | 10 | |
| 1299959 | 20 CLAMP | 6 | |
| 1366472 | 21 PLATE | 5 | |
| 1488417 | 22 REDUCER AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8941 | REDUCER | 1 | |
| 1488428 | 23 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8782 | TEE | 1 | |
| 1488451 | 24 TEE AS | 2 | |
| 6V8791 | TEE-FACE SEAL | 1 | |
| 6V9746 | SEAL-O-RING | 3 | |
| 1645544 | 25 ELBOW AS | 1 | |
| 3E2333 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3J1907 | 26 SEAL-O-RING | 3 | |
| 4J0520 | 27 SEAL-O-RING | 1 | |
| 6V8397 | 28 SEAL-O-RING | 4 | |
| 7X2533 | 29 BOLT (M6X1X35-MM) | 2 | |
| 8T4133 | 30 NUT (M10X1.5-THD) | 6 | |
| 8T4138 | 31 BOLT (M6X1X20-MM) | 2 | |
| 9X6580 | 32 NUT (1-3/16-12-THD) | 2 | |
| 9X6772 | 33 STRAP-CABLE | 8 | |
| 9X8256 | 34 WASHER (6.6X12X2-MM THK) | 6 |
