System And Components
156-8911 CAB GP-ENCLOSED ROPSS/N AKD1-762; AGG1-844
Group No: 156-8911
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8928 | 1 HOOK-COAT | 1 | |
| 7K1181 | 2 STRAP-CABLE | 26 | |
| 8C5607 | 3 MOUNT-ISOLATION | 8 | |
| 8C5608 | 4 SPACER (6.5X9.5X25.4-MM THK) | 4 | |
| 1091645 | 5 CLIP | 1 | |
| 1236449 | 6 ALARM GP (CAB) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 5P5677 | WIRE (18-GA, BLACK) | ||
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 9X1813 | SLEEVE | ||
| 1325792 | 7 INSERT-THREADED (M4X0.7-THD) | 4 | |
| 1568916 | 8 WINDOW GP-CAB | 1 | |
| 1609149 | 9 HARNESS AS-CAB (MAIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 5 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 25 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 6 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 3 | |
| 1617000 | 10 CAB AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 9B2923 | 10A HINGE | 2 | |
| 1789008 | 10B HANDLE (RH) | 1 | |
| 1789009 | 10C HANDLE (LH) | 1 | |
| 1899021 | 10D PLATE | 1 | |
| 1630152 | 11 PRESSURIZER GP-CAB | 1 | |
| 1649136 | 12 GUARD AS | 1 | |
| 1671451 | 13 DOOR GP-CAB (RH) | 1 | |
| 1671453 | 14 DOOR GP-CAB (LH) | 1 | |
| 1688929 | 15 STRIKER AS | 2 | |
| 8T4244 | NUT (M12X1.75-THD) | 1 | |
| 1293737 | STRIKER BOLT-CAB (M12X1.75X17.8-MM) | 1 | |
| 1702062 | 16 GRID | 1 | |
| 1702084 | 17 LINER GP-CAB | 1 | |
| 1702086 | 18 WIPER GP-WINDOW | 1 | |
| 1756956 | 19 COVER GP-CONSOLE | 1 | |
| 1757654 | 20 HEATER GP-CAB | 1 | |
| 1767456 | 21 HARNESS AS-WINDOW WIPER (LH) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1773851 | 22 INSULATION GP-WEATHER | 1 | |
| 1773852 | 23 STEP GP | 1 | |
| 1788375 | 24 PLATE | 2 | |
| 1789018 | 25 INDICATOR GP-AIR FILTER CHANGE | 1 | |
| 1943315 | 26 LATCH GP | 1 | |
| 1943333 | 27 INSTALLATION GP-RADIO | 1 | |
| 1967553 | 28 HANDLE AS | 1 | |
| 2110238 | 29 FILM-IDENTIFICATION (LUBE POINT) | 1 | |
| 2242470 | 30 PLATE | 1 | |
| 2242669 | 31 PLUG-PLASTIC | 8 | |
| 2V8259 | 32 GROMMET | 2 | |
| 4H2558 | 33 GROMMET | 3 | |
| 5P4116 | 34 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 5P8439 | 35 GROMMET | 1 | |
| 6V6716 | 36 RIVET-TRUSS HEAD | 2 | |
| 6V7357 | 37 BOLT (M6X1X25-MM) | 1 | |
| 7X7729 | 38 WASHER (11X25X3-MM THK) | 21 | |
| 8C8451 | 39 BOLT (M6X1X40-MM) | 4 | |
| 8E8706 | 40 MIRROR GP-REAR VIEW | 1 | |
| 8K1433 | 41 GROMMET | 1 | |
| 8T4121 | 42 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 43 NUT (M10X1.5-THD) | 2 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4189 | 45 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4195 | 46 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4198 | 47 BOLT (M10X1.5X100-MM) | 2 | |
| 9X2040 | 48 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 4 | |
| 9X6165 | 49 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 5P5952 | 50 SEAL | ||
| 1721681 | 51 SEAL |
