System And Components
156-8911 CAB GP-ENCLOSED ROPSS/N AKD1-762; AGG1-844
Group No: 156-8911
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V8928 | 1 HOOK-COAT | 1 | |
| 7K1181 | 2 STRAP-CABLE | 27 | |
| 7T8895 | 3 GROMMET | 1 | |
| 1325792 | 4 INSERT-THREADED (M4X0.7-THD) | 4 | |
| 1568916 | 5 WINDOW GP-CAB | 1 | |
| 1609149 | 6 HARNESS AS-CAB (MAIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 5 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 2 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 2 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 5 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 6 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 3 | |
| 1617000 | 7 CAB AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 9B2923 | 7A HINGE | 2 | |
| 1899021 | 7B PLATE | 1 | |
| 1630152 | 8 PRESSURIZER GP-CAB | 1 | |
| 1649136 | 9 GUARD AS | 1 | |
| 1671451 | 10 DOOR GP-CAB (RH) | 1 | |
| 1671453 | 11 DOOR GP-CAB (LH) | 1 | |
| 1688929 | 12 STRIKER AS | 2 | |
| 8T4244 | NUT (M12X1.75-THD) | 1 | |
| 1293737 | STRIKER BOLT-CAB (M12X1.75X17.8-MM) | 1 | |
| 1702062 | 13 GRID | 1 | |
| 1702084 | 14 LINER GP-CAB | 1 | |
| 1702086 | 15 WIPER GP-WINDOW | 1 | |
| 1756956 | 16 COVER GP-CONSOLE | 1 | |
| 1757654 | 17 HEATER GP-CAB | 1 | |
| 1767456 | 18 HARNESS AS-WINDOW WIPER (LH) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1773851 | 19 INSULATION GP-WEATHER | 1 | |
| 1773852 | 20 STEP GP | 1 | |
| 1789018 | 21 INDICATOR GP-AIR FILTER CHANGE | 1 | |
| 1943315 | 22 LATCH GP | 1 | |
| 1943333 | 23 INSTALLATION GP-RADIO | 1 | |
| 1967553 | 24 HANDLE AS | 1 | |
| 2242669 | 25 PLUG-PLASTIC | 8 | |
| 2282903 | 26 BRACKET AS | 1 | |
| 2292530 | 27 PLUG-PLASTIC | 1 | |
| 2292531 | 28 SEAL (DOOR, LH) | 1 | |
| 2292532 | 29 SEAL (DOOR, RH) | 1 | |
| 2313075 | 30 FILM-IDENTIFICATION (LUBE POINT) | 1 | |
| 2335153 | 31 PLATE AS | 1 | |
| 1S0994 | 32 CLIP (LOOP) | 1 | |
| 2V8259 | 33 GROMMET | 1 | |
| 4H2558 | 34 GROMMET | 3 | |
| 5P4116 | 35 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 5P8439 | 36 GROMMET | 1 | |
| 7X7729 | 37 WASHER (11X25X3-MM THK) | 21 | |
| 8E8706 | 38 MIRROR GP-REAR VIEW | 1 | |
| 8K1433 | 39 GROMMET | 1 | |
| 8T4121 | 40 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 41 NUT (M10X1.5-THD) | 2 | |
| 8T4137 | 42 BOLT (M10X1.5X20-MM) | 9 | |
| 8T4179 | 43 BOLT (M12X1.75X20-MM) | 3 | |
| 8T4189 | 44 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4195 | 45 BOLT (M10X1.5X30-MM) | 4 | |
| 9X2040 | 46 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 4 | |
| 9X2044 | 47 SCREW-TRUSS HEAD (M6X1X16-MM) | 1 | |
| 7X7702 | 48 CONDUIT-FLEXIBLE (23.35-MM ID, SPLIT)(15-CM) | ||
| 5P5952 | 49 SEAL |
