System And Components
Assembly
100%

252-2327 MOUNTING GP-ENGINE & GENERATORS/N STM1-UP

Group No: 252-2327
Part NumberPart NameQty
20634231 WASHER (22X90X6-MM THK)2
21310692 MOUNT AS2
24200053 BRACKET AS2
24221364 WASHER (27X133.3X6-MM THK)4
24773145 BRACKET AS2
24773156 BRACKET AS2
24948567 SPACER (26X133.3X3-MM THK)2
24221358 MOUNT AS4
8T68719 BOLT (5/8-11X2.5-IN)8
7X253210 BOLT (M20X2.5X130-MM)2
7X255311 BOLT (M16X2X40-MM)16
7X256712 BOLT (M24X3X160-MM)2
8T400113 NUT (M24X3-THD)4
8T412214 WASHER-HARD (17X32X3.5-MM THK)8
8T412315 WASHER (22X35X3.5-MM THK)4
8T413116 NUT (M20X2.5-THD)2
8T416717 WASHER-HARD (26X44X4-MM THK)8
8T638018 BOLT (M24X3X130-MM)2
9X825719 WASHER (17.5X30X3.5-MM THK)16
