Assembly
100%

282-6157 MOUNTING GP-ENGINE & GENERATORS/N STM1-UP

Group No: 282-6157
Part NumberPart NameQty
2P12861 LOCKNUT-BULKHEAD (1-5/16-12-THD)2
20634232 WASHER (22X90X6-MM THK)2
21310693 MOUNT AS2
24200054 BRACKET AS2
24221365 WASHER (27X133.3X6-MM THK)4
24773146 BRACKET AS4
24948567 SPACER (26X133.3X3-MM THK)2
24221358 MOUNT AS4
28260149 BASE AS-ENGINE & GENERATOR1
7X060610 WASHER-HARD (37X60X3-MM THK)2
7X255311 BOLT (M16X2X40-MM)16
7X256712 BOLT (M24X3X160-MM)2
8T400113 NUT (M24X3-THD)4
8T412214 WASHER-HARD (17X32X3.5-MM THK)8
8T412315 WASHER (22X35X3.5-MM THK)4
8T413116 NUT (M20X2.5-THD)2
8T416717 WASHER-HARD (26X44X4-MM THK)8
8T638018 BOLT (M24X3X130-MM)2
8T638119 BOLT (M20X2.5X120-MM)2
8T687120 BOLT (5/8-11X2.5-IN)8
9X825721 WASHER (17.5X30X3.5-MM THK)16
237720122 UNION (US SOURCED)2
237718023 UNION (EUROPEAN SOURCED)2
