System And Components
247-5714 LINES GP-FUEL FILTERS/N LGK157-960
Group No: 247-5714 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 5 | |
| 6V0852 | 3 CAP-DUST | 1 | |
| 6Y1352 | 4 SPACER (10.5X20X27-MM THK) | 1 | |
| 7C8246 | 5 SPACER (10.5X20X24-MM THK) | 2 | |
| 8C2948 | 6 ADAPTER-TEE | 1 | |
| 9C5344 | 7 SPACER (10.5X20X18-MM THK) | 1 | |
| 9J6189 | 8 CLIP | 1 | |
| 9X0262 | 9 ADAPTER | 1 | |
| 1057704 | 10 TEE | 1 | |
| 1236948 | 11 PLUG | 1 | |
| 1375541 | 12 PUMP GP-FUEL PRIMING | 1 | |
| 1396873 | 13 VALVE GP-FUEL BYPASS (FILTER) | 1 | |
| 1608124 | 14 PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1759079 | 15 ROD-LINK | 1 | |
| 1978391 | 16 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2336742 | 17 VALVE GP-CHECK (FUEL) | 1 | |
| 2379314 | 18 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2392396 | 19 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 2475715 | 20 BRACKET | 1 | |
| 9S1803 | 21 BOSS | 1 | |
| 0307942 | 22 ELBOW | 1 | |
| 0307947 | 23 ADAPTER-ELBOW | 2 | |
| 0308188 | 24 CONNECTOR | 1 | |
| 0672551 | 25 CLIP | 2 | |
| 1325789 | 26 CLIP (LADDER) | 1 | |
| 2067337 | 27 TUBE AS | 1 | |
| 2469354 | 28 HARNESS AS-SENSOR (FUEL) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 2R6806 | 29 CONNECTOR | 1 | |
| 9N5613 | 30 HOSE AS | 1 | |
| 2Y5829 | 31 NUT (M10X1.5-THD) | 1 | |
| 3E4352 | 32 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 3P1932 | 33 ADAPTER | 1 | |
| 4D7733 | 34 CLIP (LOOP) | 1 | |
| 4P7581 | 35 CLIP (LADDER) | 2 | |
| 5P0537 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V5230 | 37 BOLT (M10X1.5X60-MM) | 2 | |
| 6V3918 | 38 BOLT (M8X1.25X50-MM) | 1 | |
| 6V3922 | 39 SEAL-O-RING | 1 | |
| 6V3965 | 40 FITTING (QUICK DISCONNECT) | 1 | |
| 6V4589 | 41 SEAL-O-RING | 1 | |
| 6V5048 | 42 SEAL-O-RING | 1 | |
| 6V5049 | 43 SEAL-O-RING | 8 | |
| 6V5218 | 44 BOLT (M8X1.25X35-MM) | 1 | |
| 6V5839 | 45 WASHER (11X21X2.5-MM THK) | 8 | |
| 6V5842 | 46 BOLT (M10X1.5X40-MM) | 2 | |
| 6V5843 | 47 BOLT (M10X1.5X45-MM) | 2 | |
| 6V8397 | 48 SEAL-O-RING | 1 | |
| 6V8636 | 49 CONNECTOR | 1 | |
| 2591907 | 51 HOSE AS | 2 | |
| 7J9108 | 52 SEAL-O-RING | 1 | |
| 7K4129 | 53 UNION-FLARED | 1 | |
| 8L2786 | 54 SEAL-O-RING | 5 | |
| 8T0640 | 55 BOLT (M6X1X30-MM) | 1 | |
| 9M1974 | 56 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9S4185 | 57 PLUG (3/4-16-THD) | 2 | |
| 9S4191 | 58 PLUG (9/16-18-THD) | 1 | |
| 6V8212 | 59 BOLT (M10X1.5X16-MM) | 1 |
