System And Components
177-8922 AIR COMPRESSOR GP13.2 CFM. TU-FLO 550
Group No: 177-8922 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5106 | 1 BRACKET | 1 | |
| 6B6682 | 2 NUT-FULL (3/4-16-THD) | 1 | |
| 7C3179 | 3 GEAR (50-TEETH) | 1 | |
| 0907055 | 4 HOSE AS | 1 | |
| 1359819 | 5 SEAL-INTEGRAL | 1 | |
| 1494915 | 6 AIR COMPRESSOR GP | 1 | |
| 9S4191 | 7 PLUG (9/16-18-THD) | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 2N1287 | 8 ELBOW-FLARED | 1 | |
| 3D2824 | 9 SEAL-O-RING | 1 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V5049 | 11 SEAL-O-RING | 1 | |
| 6V5696 | 12 BOLT (M12X1.75X80-MM) | 2 | |
| 7J4026 | 13 ELBOW | 1 | |
| 7X0521 | 14 WASHER-HARD (20X36.5X5-MM THK) | 1 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 17 BOLT (M10X1.5X30-MM) | 2 | |
| 8T6764 | 18 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S4183 | 19 PLUG (1-1/16-12-THD) | 1 |
