System And Components
239-6363 AIR COMPRESSOR GPS/N JSC7581-UP; REH7581-UP
Group No: 239-6363 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5106 | 1 BRACKET | 1 | |
| 1359819 | 2 SEAL-INTEGRAL | 1 | |
| 1Y0683 | 3 HOSE AS | 1 | |
| 2284064 | 4 BRACKET | 1 | |
| 3346033 | 5 HOSE AS | 1 | |
| 3498383 | 6 ADAPTER AS | 1 | |
| 7J4026 | ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3893708 | 7 PLUG AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3893709 | 8 PLUG AS | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3899577 | 9 AIR COMPRESSOR GP | 1 | |
| 0016936 | 10 ELBOW | 1 | |
| 2N1287 | 11 ELBOW-FLARED | 1 | |
| 2Y5829 | 12 NUT (M10X1.5-THD) | 1 | |
| 3320011 | 13 CLIP | 1 | |
| 3574615 | 14 ELBOW AS | 1 | |
| 1412375 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V1820 | 16 BOLT (M10X1.5X30-MM) | 1 | |
| 6V4248 | 17 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5696 | 18 BOLT (M12X1.75X80-MM) | 2 | |
| 6V5839 | 19 WASHER (11X21X2.5-MM THK) | 4 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 22 BOLT (M10X1.5X30-MM) | 2 | |
| 8T6764 | 23 PLUG-PIPE (1/8-27-THD) | 1 |
