3N-9097 CLUTCH GPPART OF 3N-9098 POWER TAKE-OFF GP
Group No: 3N-9097 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B4810 | 1 LEVER AS-HAND | 1 | |
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 6L3972 | 2 PIN | 4 | |
| 6L3961 | PIN-COTTER | 4 | |
| 1L4863 | WASHER-SPRING | 8 | |
| 1L6931 | 3 SCREW AS-MACHINE (1/4-20X0.5-IN) | 2 | |
| 6L3967 | 4 PIN | 8 | |
| 6L3964 | PIN-COTTER | 8 | |
| 4B4721 | 5 LINK | 8 | |
| 3B8489 | 6 ADAPTER (1/8-27 PTF)(CLUTCH) | 2 | |
| 9S1354 | NUT (5/8-18-THD) | 1 | |
| 6F0253 | LOCKWASHER | 1 | |
| 3H9572 | 7 RING-ADJUSTMENT | 1 | |
| 5B2410 | 8 HOSE AS | 1 | |
| 4B4716 | 9 COLLAR AS-SLEEVE | 1 | |
| 0L0639 | 10 BOLT (3/8-24X2.25-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4B4758 | SHIM (0.06-IN THK) | 2 | |
| 2L6010 | 11 PLUG-PIPE | 1 | |
| 4B4782 | 12 RETAINER | 1 | |
| 3F3729 | 13 RING-SNAP | 1 | |
| 4L3527 | 14 PLATE-CLUTCH DRIVING | 1 | |
| 4H0002 | 15 LEVER | 4 | |
| 3N4086 | 16 SHAFT-CLUTCH | 1 | |
| 8B1303 | 17 HOUSING-CLUTCH | 1 | |
| 1083560 | PLATE-WARNING (POWER TAKE-OFF) | 1 | |
| 1B3922 | 18 CUP-BEARING | 2 | |
| 6B3183 | CONE-BEARING | 2 | |
| 7L0116 | 19 LOCK | 1 | |
| 2H3755 | 20 BOLT (5/16-18X0.43-IN) | 1 | |
| 3F9556 | LOCKWASHER | 1 | |
| 4B4792 | 21 YOKE AS | 1 | |
| 0S1591 | 22 BOLT (3/8-16X1.5-IN) | 2 | |
| 3B4506 | LOCKWASHER | 2 | |
| 8B7121 | 23 FITTING-HYDRAULIC (CLUTCH) | 2 | |
| 6L5151 | 24 KEY-WOODRUFF | 2 | |
| 4B4754 | 25 SHAFT | 1 | |
| 1L5517 | 26 SLEEVE-THROW-OUT | 1 | |
| 3N8125 | 27 PLATE AS-PRESSURE | 1 | |
| 3N8123 | 28 LOCK PIN | 1 | |
| 3N8124 | 29 SPRING | 1 | |
| 5N9316 | 30 RING-DRIVE | 1 | |
| 4B4752 | 31 NUT | 1 | |
| 4B4772 | 32 LOCK | 1 | |
| 5B2417 | 33 KEY | 1 | |
| 1L5516 | 34 PLATE-CLUTCH | 1 | |
| 1083633 | 35 PLATE-INSTRUCTION (POWER TAKE-OFF) | 1 |
