250-1887 DRIVE GP-FANAN ATTACHMENT

Group No: 250-1887 · Commonality
Part NumberPart NameQty
11172381 PLATE (THRUST)1
12308562 SHAFT-FAN1
13370233 PULLEY AS-IDLER1
1512898SPACER (10.4X38.1X20-MM THK)1
1512900BOLT (M10X1.5X54.25-MM)1
1666358COVER-DUST1
27925894 PULLEY AS-IDLER (8-GROOVE)2
1512900BOLT (M10X1.5X54.25-MM)1
1666358COVER-DUST1
19006345 BELT TENSIONER1
20022826 BEARING AS1
20141187 PULLEY-FAN (8-GROOVE)1
20151498 SUPPORT AS-FAN1
5B5821DOWEL1
20151519 BRACKET1
201515210 SPACER1
207599211 BRACKET1
211210112 SLEEVE2
222288013 BELT TENSIONER1
226791414 BRACKET (FAN BEARING)1
228582715 RETAINER-BEARING1
250188816 BRACKET AS1
132755117 SPACER (11X19X6-MM THK)1
6V182018 BOLT (M10X1.5X30-MM)4
6V382219 BOLT (M10X1.5X35-MM)3
6V394020 BOLT (M8X1.25X25-MM)3
6V424821 BOLT (M10X1.5X25-MM)1
6V521522 BOLT (M8X1.25X16-MM)1
6V521723 BOLT (M8X1.25X20-MM)9
6V521924 BOLT (M8X1.25X40-MM)2
6V583925 WASHER (11X21X2.5-MM THK)16
6V584226 BOLT (M10X1.5X40-MM)4
6V798127 BOLT (M10X1.5X70-MM)2
8T064328 BOLT (M10X1.5X80-MM)1
8T908529 BOLT (M10X1.5X150-MM)1
9M197430 WASHER-HARD (8.8X16X2-MM THK)3
